ABB Stotz S&J multifunction time relay CT-MVS.12S

Manufacturer: ABB Stotz S&J
Designation: Multifunction time relay 24-48VDC 24-240VAC
Type: CT-MVS.12S
Version of electrical connection: Screw connection
Function response-delayed: Yes
Function off-delayed: Yes
Function switch-on wiping: Yes
Function switch-off wiping: Yes
Function star/delta: No
Function pulse forming: Yes
Function flashing with pause starting, fixed time: No
Function flashing starting with pulse, fixed time: Yes
Function pulsing starting with pause, variable: No
Function pulsing starting with pulse, variable: No
With plug-in base: No
Remote control possible: No
Suitable as remote control: No
Can be plugged onto contactor: No
Rated control supply voltage Us at AC 50 Hz: 24..240 V
Rated control supply voltage Us at AC 60 Hz: 24..240 V
Rated control supply voltage Us at DC: 24..48 V
Voltage type for actuation: AC/DC
Rated current: 4 A
Time range: 0.05...1080000 s
Number of outputs, undelayed, change-over: 1
Number of outputs, delayed, change-over: 1
Outputs, switchable delayed/undelayed: No
With semiconductor output: No
Suitable for top-hat rail mounting: Yes
Suitable for front mounting: No
Width: 22.5 mm
Height: 85.6 mm
Depth: 103.7 mm

The CT-S series is ABB's most economical and universal time relay series. The range comprises 16 multi-function devices and 26 single-function devices with up to 11 functions, allowing maximum flexibility in use. The devices have 7 or 10 time ranges that can be set from 0.05 seconds to 300 hours. In addition, an extended temperature range of -40 °C to +60 °C is possible with selected units.
EAN: 4016779851398.
