Bernstein aluminium enclosure GEH.CA-215

Manufacturer: Bernstein
Designation: Aluminium enclosure
Dimensions: 122 x 122 x 90 mm
Type: GEH.CA-215
Mounting type: Other
Cover type: Closed
Door type: Without
Transparent cover/door: No
With lock: No
Height: 90 mm
Width: 122 mm
Depth: 122 mm
Material thickness of housing: 4.1 mm
Material thickness of door/lid: 4 mm
Colour: Grey
RAL number: 7001
Mounting option: Yes
Enclosure material: Aluminium
Surface protection: Powder-coated
With mounting plate: No
Suitable for outdoor use: No
Suitable for lightning protection: No
Protection class (IP): IP67
Protection class (NEMA): Other
Protection class: I
Impact resistance: IK09
Cover with pressure relief: No

Further details:
Empty enclosure for high mechanical load capacity. Protection class IP66/IP67 according to DIN EN 60529. Corrosion and impact resistant due to high-quality powder coating. Earthing screws in the base and cover for holding protective conductors. Fastening bars for holding and fastening fixtures (mounting rail, mounting plate, etc.). Material: Die-cast aluminium. Seal: Foamed PUR seal. Cover screws: Stainless steel, captive, combination Phillips head. Temperature range: -30°C to +80°C. EAN: 4024337018107.
