Eaton Power contactor, 3-pole, 380 V 400 V 7.5 kW, 1 S, 220 V DC, DC actuation, screw terminals 2
Price in EUR including VAT
free shipping
Contactor, Application: Contactor for motors, contactors up to 170 A, 3-pole, Utilisation category: AC-1: Non-inductive or weakly inductive load, resistance furnaces, AC-3: Squirrel cage motors: Starting, switching off while running, AC-4: Squirrel cage motors: Starting, counter-current braking, reversing, inching, Connection technology: screw terminals, Note: Not suitable for motors of efficiency class IE3., Poles: 3-pole, Rated operating current AC-3 380 V 400 V: Ie= 15.5 A, Rated operating current AC-1 conventional thermal current, 3-pole, 50 - 60 Hz open at 40 °C: Ith = Ie= 22 A, encapsulated: Ith= 18 A, rated operating current AC-1 conventional thermal current 1-pole open: Ith= 50 A, encapsulated: Ith= 45 A, max. rated operating power three-phase motors 50 - 60 Hz AC-3 220 V 230 V: P= 4 kW, 380 V 400 V: P= 7.5 kW, 660 V 690 V: P= 7 kW, max. Rated operating power three-phase motors 50 - 60 Hz AC-4 220 V 230 V: P= 2 kW, 380 V 400 V: P= 3 kW, 660 V 690 V: P= 4.4 kW, can be combined with auxiliary switches: DILM32-XHI.., DILA-XHI(V).., contact configuration S = NO contact: 1 S, Notes: Switching elements according to EN 50012, Integrated varistor protection circuit, Current type AC/DC: Direct current actuation.
input voltage | 220 V |
Scope of delivery | 3-pole, AC-3: Squirrel cage motors: Starting, AC-4: Squirrel cage motors: Starting, Application: Power contactor for motors, Connection technology: Screw terminals, Contactors up to 170 A, Counter-current brakes, Note: Not suitable for motors of efficiency class IE3., Power contactor, Resistance furnaces, Switch off during the run, Tap, Utilisation category: AC-1: Non-inductive or weakly inductive load |
Output current type | AC |
Relay type | Power contactor |
Item number | 41011705 |
Relay type | Power contactor |
input voltage | 220 V |
Output current type | AC |
Switching function | Normally open |
Number of closers | 3 x |
Number of poles | 3 x |
Max. Switching capacity | 7.50 kW |
Manufacturer Type | 3-pole, Power contactor |
Smart Home | Not compatible |
CO₂-Emission | |
Climate contribution |
Scope of delivery | 3-pole, AC-3: Squirrel cage motors: Starting, AC-4: Squirrel cage motors: Starting, Application: Power contactor for motors, Connection technology: Screw terminals, Contactors up to 170 A, Counter-current brakes, Note: Not suitable for motors of efficiency class IE3., Power contactor, Resistance furnaces, Switch off during the run, Tap, Utilisation category: AC-1: Non-inductive or weakly inductive load |
