TE Sensors Inductive Proximity Switch XS530B1CAM12

Manufacturer: TE Sensors
Description: Inductive proximity switch M30, Sn 10 mm
Type: XS530B1CAM12
Length of the sensor: 62.2 mm
Diameter of the sensor: 30 mm
Mechanical installation condition for the sensor: flush
Switching distance: 10 mm
Suitable for safety functions: no
Type of switching function: normally open
Type of switching output: 2-wire
Type of electrical connection: M12 connector
Number of semiconductor outputs with signaling function: 1
Number of safe semiconductor outputs: 1
Type of actuation: metallic target
Interface design: none
Interface design for safety-related communication: none
Housing design: cylinder, threaded
Housing coating: nickel-plated
Cascadable: no
SIL according to IEC 61508: none
Performance Level according to EN ISO 13849-1: none
Max. output current at safe output: 100 mA
Supply voltage: 12..48 V
Rated control supply voltage Us at DC: 12..48 V
Type of voltage: AC/DC
Switching frequency: 2000 Hz
With monitoring function for downstream devices: no
Material of the housing: metal
Pressure-resistant: no
Explosion protection category for gas: none
Explosion protection category for dust: none
Immunity to magnetic fields: immune to magnetic static fields

TE Sensors Inductive Proximity Switch XS530B1CAM12: further details
XS5 Inductive proximity switch in cylindrical design M30, length 74 mm, brass, switching distance Sn 10 mm, power supply 12-48 V DC, M12 connector.
EAN: 3389110405187.
