Schneider Electric Relay ABR7S33

Manufacturer: Schneider Electric
Designation: Relay 12.5 mm, 24 VDC, 1 CO
Type: ABR7S33
Function: semi-electronic
Mounting type: DIN rail
Installation depth: 55 mm
Number of contacts as changeover: 1
Control voltage 1: 24 V
Control voltage type 1: AC/DC
Control voltage type 2: AC/DC
Rated current: 0.1 A
Supply voltage: 230 V
Voltage type of supply voltage: AC/DC

Further details:
This product is part of the Modicon ABE7 range, an offering of connection bases for the pre-wired Telefast system. This pluggable electromechanical relay is compatible with the Modicon ABE7 connection bases. It has 1 changeover contact. It is a semiconductor relay with a control voltage of 24 V DC, a conventional thermal air load current of 10 A, and a maximum power loss per pole of 0.6 W. It offers an electrical lifespan of 500,000 cycles and a mechanical lifespan of 20 million cycles. The width is 12 mm. It weighs 0.017 kg. It is suitable for all types of industrial applications. This product is compatible with Modicon ABE7P08T330E, ABE7R16T332, ABE7P16T334, ABE7P16T318E, ABE7P16T318, ABE7P16T332, ABE7P16T330, ABE7R16T330, ABE7P16T330E and the connection plate ABE7P08T330. Modicon ABE7 simplifies the wiring of your automation system. Pre-wired system that allows the connection and adjustment of control signals for PLC cards equipped with HE10 connectors.
