Sick safety light curtains C4C-SA09030A10000 Manufacturer :Sick Designation :Safety light curtains Type :C4C-SA09030A10000 Blanking possible :no Design of the interface for safety-related communication :DeviceNet Safety Design of the electrical connection :M12 plug connector Equipment protection class :Protection class 3 Detection capacity for test specimen :30 mm Explosion protection category for gas :none Explosion protection category for dust :none Cascadable :no Scope of delivery of the one-way system :Receiver Ambient temperature :-30..55 °C With muting function :no Override possible :no Resolution of the light curtain :14 mm Protective field height :300 mm Safety type according to IEC 61496-1 :4 Rated control supply voltage Us at DC :19.2..28.8 V Voltage type :DC With beam coding :no Cycle control possible :no With monitoring function of downstream devices :no Wavelength of sensor :850 nm With restart interlock :no Suitable for safety functions :yes Protection class (IP) :IP67 Sick safety light curtains C4C-SA09030A10000: Further details Safety light curtains, deTec, C4C-SA09030A10000, deTec variant: deTec4 Core, System part: transmitter, Application area: standard industrial environment, Safety level: Type 4, PL e, SIL3, SILCL3, Resolution: 30 mm, Range: 15 m, Protective field height: 900 mm, Connection type: plug M12, 5-pin, Protection type: IP65, IP67, Scope of delivery: transmitter , EAN: 4047084248115.
