The sensor for C-Nut cylinders from Sick, model MZCG-1Z7PS-KR0, is a highly advanced electronic module specifically designed for use in cylinder systems. With a robust construction and an IP68 protection rating, this sensor is ideal for demanding environments. It offers a reliable switching function as a normally closed contact and is equipped with a PNP switching output. The electrical connection is made via a 3-wire system that supports an operating voltage of 10 V DC to 30 V DC. The sensor comes with a 0.5 m long cable with a 3-pin M8 connector, allowing for easy installation. Thanks to its high protection class III and EMC compliance according to EN 60947-5-2, the sensor is protected against short circuits as well as electromagnetic interference. This makes it an excellent choice for industrial applications where reliability and durability are crucial.

• IP68 protection rating for use in harsh environments
• EMC compliant according to EN 60947-5-2
• Robust construction with knurled screw connection
• Built-in short circuit protection
• Switching status LED for status indication.
