Steel Contact Element 8082/1-2-00

Manufacturer: Steel
Description: Contact element
Type of normally closed contact: 8082/1-2-00
Number of contacts as normally closed: 1
Rated operational current Ie at AC-15, 230 V: 6 A
Type of electrical connection: Screw connection
Design: Integrable
Mounting type: Other
Socket: None

The contact elements of the 8082 series from R. STAHL feature a normally closed contact and a force-opening normally open contact, made either of silver-nickel or gold-plated. They can be easily combined into contact blocks and allow for customized installations, thanks to the wide selection of different actuating heads.

Contact element, explosion-proof, type: 8082/1-2-00, number of normally closed contacts: 1, connection type: screw terminal, 2.5 mm² fine-stranded, housing material: polyamide, contact material: silver-nickel, application area (zones): 1, 2, ambient temperature min.: -60 °C, ambient temperature max.: +70 °C, gas explosion protection: II 2 G Ex db eb IIC Gb, impact weather protection: I M2 Ex db eb I Mb.
