Turck connection cable RSS8T-10/TXL Manufacturer :Turck Designation :Connection cable PUR Type :RSS8T-10/TXL Number of poles :8 Version of electrical connection, housing side :M12 Type of plug-in contact, housing side :Male (plug) Arrangement of cable entry, housing side :straight Cable length :10 m Material of cable sheath :Polyurethane (PUR) Colour of cable sheath :black With LED display :no Shielded :yes Cable type :multi-core Material of contact base :CuZn Material of contact coating :Gold Perm. Permissible cable outer temperature after assembly without vibration :-50..80 °C Permissible cable outer temperature during assembly/handling :-50..80 °C Permissible cable outer temperature during assembly/handling :-25...80 °C Rated current In :2 A Rated voltage :30 V Turck connection cable RSS8T-10/TXL: further details Actuator and sensor cable / PUR, connection cable, M12 connector, straight, 8-pin, shield connected to union nut/screw, cable length: 10 metres, sheath material: PUR, shielded, sheath colour: black, suitable for drag chains, resistant to welding sparks, resistant to chemicals, UV and oil, flame retardant, free of halogen, silicone, PVC and LABS, especially abrasion resistant, approval: cULus, RoHS compliant, protection class IP67 , EAN: 4047106160326.
Cable length | 10 m |
Plug type | M12 |
Item number | 36814827 |
Manufacturer | Turck |
Category | Power cables |
Manufacturer no. | 6625466 |
Release date | 28.6.2023 |
Cable colour | Black |
Material of the isolation | Polyurethane |
Wall socket | 8-pole |
Plug type | M12 |
Plug type | Flat |
American Wire Gauge (AWG) | 8 |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Cable length | 10 m |
