Turck Valve plug connector type BI Connection cable VIS02-A80E-10/TXL
Product details
Turck valve connector VIS02-A80E-10/TXL Manufacturer :Turck Designation :Valve connector Design BI Type :VIS02-A80E-10/TXL Number of poles :3 Version electrical connection, housing side :other Type of plug contact, housing side :Male Cable length :10 m Cable sheath material :Polyurethane (PUR) Cable sheath colour :black With LED indicator :no Shielded :no Cable type :multicore Contact body material :CuSn Contact coating material :silver Perm. External cable temperature after installation without vibration :-40..80 °C Perm. Permissible external cable temperature during installation/handling :-30...90 °C Rated current In :4 A Rated voltage :230 V Turck valve connector VIS02-A80E-10/TXL: further details Valve connector design BI, connection cable, 2-pole + PE, design according to standard DIN EN 175301-803, RoHS-compliant, protection class: IP65, IP67, IP68, without protective circuit, without LED, cable length: 10 metres, sheath material: PUR, sheath colour: black, suitable for drag chains, resistant to welding sparks, resistant to chemicals and oil, UV and ozone resistant, flame retardant, halogen, silicone, PVC and LABS-free, EAN: 4047101373509.
Plug type | DC connector |
Cable + connector type | Plug connectors |
Cable length | 10 m |
Item number | 36330224 |
Manufacturer | Turck |
Category | Cables + Plugs |
Manufacturer no. | 6606848 |
Release date | 15.6.2023 |
Colour | Black |
Material group | Plastic |
Material | Polyurethane (PUR) |
Cable + connector type | Plug connectors |
Plug type | DC connector |
Compatible hardware | Various |
Max. temperature | 80 °C |
Min. temperature | -40 °C |
Cable length | 10 m |
Manufacturer Type | TXL, VIS02-A80E-10 |
Number of cores | 3 x |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Items per sales unit | 1 Piece |
Scope of delivery | 2-pole + PE, Cable length: 10 metres, Coat colour: black, Connection cable, Design according to standard DIN EN 175301-803, Flame retardant, Halogen, Ip67, IP68, Jacket material: PUR, Protection class: IP65, PVC- and LABS-free, Resistant to chemicals and oil, RoHS-compliant, Silicone, Suitable for drag chains, sweat spark-proof, UV and ozone resistant, Valve connector type BI, without LED, without protective circuit |
Length | 1000 cm |
