Walther Werke Socket insert BV10 730110 Manufacturer :Walther Werke Designation :Socket insert BV10 Screw connection Type :730110 Number of power contacts :8 Number of control contacts :2 Contact insert without contacts :no Contact design :Socket Number of poles :10 Diameter of the plug-in contact :2.5 mm Material of the plug-in contact insert :Thermoplastic Rated current In :16 A Ambient temperature :-40...125 °C Operating temperature :-40...125 °C Rated voltage :400 V Rated impulse voltage :6 kV Overvoltage category :III Pollution degree :3 Design of electrical connection :Screw connection With wire protection :yes Connectable fine-stranded conductor cross-section without wire end ferrule :2.5 mm² Connectable fine-stranded conductor cross-section with wire end ferrule :0 mm² Connectable conductor cross-section solid :0 mm² Connectable conductor cross-section stranded :2.5 mm² Material of contact coating :silver Material of contact insert :other Material of contact :other copper alloys Flammability class of insulation material according to UL 94 :V0 With protective conductor :yes Min. Number of mating cycles :500 Width :111 mm Height :37 mm Depth :34 mm Walther Werke socket insert BV10 730110: further details WALTHER socket insert of the BV10 series with screw connection and wire protection , EAN: 4015609032457.
