Best Phoenix Contact products in the Relays category
On this page you'll find a ranking of the best Phoenix Contact products in this category. To give you a quick overview, we've already ranked the most important information about the products for you.
1. Phoenix Contact PLC-RSC- 230UC/21-21
The LOW PROFILE interface relay from Phoenix Contact is a highly developed product designed for mounting on NS 35/7.5 DIN rails. It is a complete device consisting of a base terminal with a screw connection and a pluggable miniature relay with a power contact. This relay features two changeover contacts and is designed for input voltages of 230 V AC and 220 V DC. With a rated current of 6 A, it is ideal for various applications in automation technology. The relay is equipped with an LED display that indicates the operating status and offers monostable switching behavior. The IP20 protection rating ensures that the device is suitable for use in dry indoor environments. Its compact design and easy installation make it a practical solution for many industrial applications.
- Two changeover contacts for flexible switching options
- LED display for status monitoring
- Monostable switching behavior for reliable performance
- Screw connection for easy installation
- IP20 protection rating for use in dry indoor environments.
2. Phoenix Contact Interface relay 10 pcs. 24 V/DC
PLC interface consisting of a base terminal and a pluggable miniature relay with multilayer gold contact, designed for mounting on a mounting rail NS 35/7.5.
3. Phoenix Contact Relay module
The relay module from Phoenix Contact is a pre-assembled installation relay designed for a nominal voltage of 125 V/DC. It offers a reliable switching option with a maximum switching current of 6 Amperes. The module consists of a relay socket, a power contact relay, and a retaining bracket, allowing for easy installation and handling. The contact configuration includes four changeover contacts, providing versatile application possibilities. This relay module is ideal for various industrial applications where precise control and switching are required.
- Pre-assembled design for easy installation
- Maximum switching current of 6 A
- Output voltage of up to 250 V AC
- Robust construction with screw connection.
4. Phoenix Contact PLC-RSC- 24DC/21/MS
Coil voltage: 24 V dc
Switching current: 6 A
Mounting type: DIN rail
Connection type: Screw
Length: 94 mm
Series: PLC-RSC
Height: 80 mm
Dimensions: 94 x 80 x 6.2 mm
Contact material: Silver alloy
Inrush current: 15.3 mA
Minimum operating temperature: -40 °C
The PLC-RSC series includes single and double pole relays as well as optocouplers for PLC interfaces, all featuring the same profile. Therefore, the modules can be installed in any configuration using a common bridging system and the same accessories. The V8 adapter connects 8 relays or optocouplers to a 15-pin D-SUB cable.
Features and benefits:
- Relays and optocouplers for inputs and outputs with pluggable circuit components
- Four bridging slots for reduced wiring effort; bridging of up to 80 modules possible
- Screw terminal connections
- LED indicators and diodes for coil suppression
- 250 V versions with a rated power of 1500 VA
- Dimensions (W x D x H): 6.2 x 80 x 94 mm (single pole, double pole 14 mm wide)
- Operating temperature range: -40 to +55 °C
- Mechanical lifespan (relays): 1 x 10^7 switching cycles
- Extensive selection of accessories also available.
5. Phoenix Contact Tc Mobile I/O X200-4G
Additionally, the device can remotely switch relay outputs. It offers many helpful software features such as an SMS alert chain, SMS notifications for voltage drops, logbook sending via email, and different user roles. To configure it, you only need a USB connection to a computer with a web browser.
6. Phoenix Contact PLC-RPT- 24UC/21-21/
The Phoenix Contact PLC-RPT-24UC/21-21 is a highly advanced installation relay specifically designed for railway applications. It provides a reliable solution for control and automation in demanding environments. With a rated voltage of 24 V DC and a maximum switching current of 6 A, this relay ensures effective performance. The temperature class TX allows operation over a wide temperature range of -40 °C to +70 °C, making it ideal for use in extreme conditions. The product features two changeover contacts and is equipped with a push-in connection that enables easy and secure installation. The compact design of the relay module ensures it can be used in various applications without taking up much space.
- Temperature class TX: -40 °C to +70 °C
- Maximum switching current of 6 A
- Two changeover contacts for flexible switching options
- Push-in connection for easy installation.
7. Phoenix Contact Safety relay
The safety relay from Phoenix Contact is a highly advanced auxiliary relay specifically designed for two-hand controls. It meets the requirements of ISO 13851 Type IIIC and provides a reliable safety solution up to SIL 3 or Category 4 according to EN ISO 13849. With a simultaneity monitoring of less than 0.5 seconds, it ensures precise and safe control in industrial applications. The device is equipped with two normally closed contacts and one normally open contact, offering a secure separation to ensure user safety. The pluggable screw terminals allow for easy installation and maintenance, while the compact design of 22.5 mm width enables space-saving integration into existing systems.
- Two-hand controls according to ISO 13851 Type IIIC up to SIL 3 or Cat. 4, PL e according to EN ISO 13849
- Simultaneity monitoring of less than 0.5 seconds
- Equipped with 2 normally closed contacts and 1 normally open contact for flexible applications
- Pluggable connection terminals for easy installation and maintenance.
8. Phoenix Contact RIF-1-RPT-LDP-24DC/2X21/FG
The RIF-1-RPT-LDP-24DC/2X21/FG from Phoenix Contact is a pre-assembled installation relay designed for reliable control in various applications. It features a push-in connection that allows for easy and secure wiring. The module consists of a relay base and a safety relay with forcibly guided contacts that meet the requirements of the standard DIN EN 61810-3. A pluggable display and troubleshooting module, as well as a retaining bracket, are also included, making installation and maintenance easier. With an input voltage of 24 V DC and a contact configuration of two changeover contacts, this relay module offers versatile applications in automation technology and mechanical engineering.
- Forcibly guided contacts according to DIN EN 61810-3 for increased safety
- Push-in connection for easy and secure wiring
- Pluggable display/troubleshooting module for easy maintenance
- Operating temperature range of 20 to 50 °C for flexible application possibilities.
9. Phoenix Contact Interface Relay Module
Switching current: 1 A
Mounting type: PCB mounting
Connection type: PCB pin
Length: 29 mm
Series: VARIOFACE
Height: 15.7 mm
Dimensions: 29 x 12.7 x 15.7 mm
Contact material: Silver alloy
Input current: 4.1 mA
Number of poles: 2
The PLC-RSC series includes single and double pole relays as well as optocouplers for PLC interfaces, all sharing the same profile. Therefore, the modules can be installed in any configuration using a common bridging system and the same accessories. Through the V8 adapter, 8 relays or optocouplers can be connected to a 15-pin D-SUB cable.
Features and benefits:
- Relays and optocouplers for inputs and outputs with pluggable circuit components
- Four bridging slots for reduced wiring effort; bridging of up to 80 modules is possible
- Screw terminal connections
- LED indicators and diodes for coil suppression
- 250 V versions with a rated power of 1500 VA
- Dimensions (W x D x H): 6.2 x 80 x 94 mm (single pole, double pole 14 mm wide)
- Operating temperature range: –40 to +55 °C
- Mechanical lifespan (relays): 1 x 10^7 switching cycles
- A wide range of accessories is also available.
10. Phoenix Contact Relay module Relay module RIF 2 RPT
Pre-assembled relay module with push-in connection, consisting of a relay base, power contact relay with additional hard gold plating, and retaining bracket. Contact type: 4 changeover contacts. Input voltage: 24 V DC.
