Dimensions and Technical Data

• 220-240 V ~ 50 Hz
• Cover Color: glossy red
• Cover Material: glass
• Speed Levels: 1
• Nominal Diameter: 100 mm
• Power: 5 W
• Revolutions per Minute: 1900
• Max. Air Flow: 75 m³/h
• Sound Pressure Lp-3m: 26 dB(A)
• Total Pressure Pmax.: 26 Pa
• Protection Class: IPX4
• Max. Ambient Temperature: +40°C
• Diameter of Pipe Connector: 100 mm
• Front Cover: 159 x 159 x 38 mm
• Total Depth: 126 mm
• Weight: 0.7 kg
• Adjustable Run-On Time (3-30 min), Motion Sensor: automatic activation upon motion detection, device turns off after the set run-on time
• Mounting Options: Wall
• Installation: directly in the ventilation duct.
