Dimensions and technical details:

• Voltage: 220-240 V ~ 50 Hz
• Front panel color: white
• Front panel material: ABS plastic
• Nominal size: 100 mm
• Speed levels: 1
• Wattage: 13 W
• Revolutions per minute: 2400
• Max. airflow rate: 110 m³/h
• Sound pressure level (Lp-3m): 36 dB(A)
• Total pressure (Pmax): 40 Pa
• IP rating: IPX4
• Max. ambient temperature: +40°C
• Diameter pipe connection: 100 mm
• Front cover dimensions: 160 x 160 x 30 mm
• Total depth: 118 mm
• Weight: 0.7 kg

Features:

• Adjustable shut-off timer (3-30 min)
• Motion sensor: fan automatically turns on when sensing movement and turns off after the pre-set time
• Mounting options: wall or ceiling
• Application: direct connection to the ventilation shaft.
