Assa Abloy effeff Security Lock 709X602 709X602PZ-G41

Manufacturer: Assa Abloy effeff
Description: Universal Security Lock 709X602
Type: 709X602PZ-G41
Execution: Security Lock with Push Button Control
Voltage: 12-24 V
Opening Direction according to DIN: Left/Right
Mounting Type: Built-in
Current Type: DC

The security lock with push button control is primarily used where the advantage of a push button-operated release must be combined with the mechanical security requirements of lock models 309X and 409X. The integrated monitoring contacts allow for the querying of essential lock states. The bolt is retracted by the coupled external push button, releasing the locking of the deadbolt. When closing the door, the control bolt interacts with the deadbolt to exclude the pre-tensioned bolt and lock the deadbolt, thus serving as an additional locking mechanism.

The adjustment of the panic side and the selection between standby and working current can be made at the lock if necessary.

• Mechanical self-locking
• Mechanical control of the deadbolt and control bolt
• With deadbolt, therefore convertible for DIN L / DIN R doors
• Panic side convertible
• Standby/working current convertible
• Burglary-resistant due to massive bolt with 20 mm exclusion
• Panic function
• Approval according to EN 179
• Approval according to EN 1125
• Suitable for fire protection doors
• Controllable external push button
• Change function for unlocking via key from outside
• Monitoring functions

The locks of the 709X model series have a split push button and therefore require an internal push button (or a panic handle) and an external push button. The control of the lock is activated by a pulse from a card reader, code lock, timer, button, etc.
EAN: 4042203169869.
