EVN-Lichttechnik LED recessed floor luminaire
1052 lm, IP67Product details
The housing of the recessed floor light is made of solid aluminum, while the upper cover ring is made of V2A stainless steel, making it suitable for a variety of outdoor applications. Installation is done using the plastic installation sleeve included in the delivery. Since the COB LED chip is permanently installed, there are no additional costs for light bulbs. Additionally, there are no extra costs for a ballast, as the connection is made directly to the 230V supply line. Furthermore, there is a self-venting valve on the underside. The maximum drive-over speed is 20 km/h. The beam angle is 10°. When using the optionally available frosted glass, the light output is reduced to 915 lm. The light comes with a 0.50 m long connection cable with free wire ends.
Power supply | Electrical connection |
Height | 12.50 cm |
Dimmability | Not dimmable |
Protection type (IP code) | IP67 |
Item number | 36789834 |
Manufacturer | EVN-Lichttechnik |
Category | Outdoor lighting |
Manufacturer no. | 683870 |
Release date | 28.6.2023 |
Colour | Silver |
Exact colour description | Aluminium, Stainless steel |
Material group | Metal |
Material | Aluminium, Stainless steel V2A |
Application range | Outdoor |
Garden lighting type | Outdoor wall lamp |
Model series | PC67101202S |
Adjustability | None |
Dimmability | Not dimmable |
mounting style | Set in concrete |
Shape | Round |
Bulb type | LED |
Luminous flux | 1052 lm |
Light colour | White |
Colour temperature | 3000 K |
Shielding angle | 10° |
Scope of illuminant | incl. fixed light bulb |
Number of lights | 1 x |
Max. power per lamp | 12 W |
Smart Home | Not compatible |
Smart home ecosystem | Apple Home, Google Assistant |
Communication standard | Amazon Alexa, IFTTT |
Power supply | Electrical connection |
input voltage | 230 V |
Power consumption | 12 W |
Cable length | 0.50 m |
Protection type (IP code) | IP67 |
Protection class | Protection class I |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Items per sales unit | 1 x |
Scope of delivery | 12W 3000K, Can be driven on up to 1500kg at max. 20km/h, Glass Clear, Input voltage 230V-AC, LED in-ground light IP67, Stainless steel V2A (observe care instructions), Supply cable H05RR-F 50cm and plastic installation pot (sufficient drainage required), with integrated power supply unit, with vent valve (self-venting) |
Delivery condition | Self-assembly |
Diameter | 18 cm |
Length | 12 cm |
Height | 12.50 cm |
