Specification Topology Transformerless Supported connection cross-sections 2.5 - 16 mm² Connection RS485 Cooling system Ventilated Number of phases 3 Application Solar collector Reverse polarity protection Yes Overload protection functions Overload protection functions DC offset Current type DC/AC Efficiency 98 % I Protection class WLAN Yes Power supply type Indoor/outdoor IP protection class IP65 Wired LAN Yes Certifications ÖVE / ÖNORM E 8001-4-712, DIN V VDE 0126-1-1/A1, VDE AR N 4105, IEC 62109-1/ -2, IEC 62116, IEC 61727, AS 3100, AS 4777-2, AS 4777-3, CER 06-190, G83/2, UNE 206007-1, SI 4777, CEI 0-21, NRS black Colour 097 Grey Integrated display Yes Cooling type Active Number of MPP trackers 2 max. Short-circuit current in module field 24 / 24 A strings per track MPP 2+2 Apparent power 6000 VA MPPT voltage range 150 - 800 V Output frequency 50 /60 Hz Active power 6000 W Maximum input power 12000 W Output current 8.7 A Starting voltage 200 V Input voltage 150 - 1000 V Input current (max.) 16 A) 16 A Mains voltage range 3-NPE 400 V / 230 V / 3~NPE 380 V / 220 V (+ 20 % / -30 %) Product height 645 mm Product weight 19.9 kg Product width 431 mm Product depth 204 mm Relative humidity range 0 - 100 % Temperature range (operation) -25 - 60 °C Quantity Packaging 1 pc. Width 550 mm Length 285 mm Height 780 mm.
