Power supply: 380~415V/3Ph/50Hz

Rated heat at (Max) (A7/6?,W30/35?):

• Heat output: 24.33kW (6.50-26.10)
• Power consumption: 5.10kW
• COP W/W: 4.77

Nominal heat at (Max) (A7/6,W47/55):

• Heat output: 24.29kW
• Power consumption: 7.93kW
• COP W/W: 3.06

Cooling capacity at (Max) (A35/24,W12/7):

• Cooling capacity: 20.89kW
• Power consumption: 6.70kW
• EER W/W: 3.12

ERP at water outlet temperature 35: A+++
ERP at water outlet temperature 55: A++

MAX. Power consumption: 9.38kW
MAX. current consumption: 17.30A

Refrigerant: R32

Rated water flow: 4.20m³/h

Number of fans: 2

Sound pressure at 1 m distance: 55dB(A)

Maximum water temperature at outlet: 60°C

Water pipe connections: DN 40 (1.5")
Water pressure loss (max): 32kPa

Device size (L×D×H): 1050×420×1250mm
Packaging size (L×D×H): 1100×480×1400mm

Appliance weight: 174kg
Appliance weight with packaging: 194kg.
