Jung Schuko Socket 16 A 250V SPLS 1520 NKI WW

Manufacturer: Jung
Description: Schuko socket 16 A 250V with touch protection
Type: SPLS 1520 NKI WW
Design: Schuko
Protective contact: yes
Round protective earth contact: no
Number of active contacts (round): 2
With signal lamp: no
With built-in USB power supply: no
Number of units: 1
Number of phases: 1
Connection type: screw terminal
With flap cover: no
With increased touch protection: yes
Text field/labeling area: no
Color: white
RAL number (similar): 9016
Metallic color: no
Transparent: no
Lockable: no
Ejection mechanism: no
With functional lighting: no
With orientation light: no
Surge protection: no
Residual current protection: no
With fine fuse: no
Special power supply: without special power supply
Mounting type: flush-mounted
Mounting method: screw fastening
Halogen-free: yes
Antibacterial treatment: yes
With on/off switch: no
With pass-through function: no
Twisted central insert: no
Rated current: 16 A
Rated voltage: 250 V
Suitable for protection class (IP): IP20
Device width: 70 mm
Device height: 70 mm
Device depth: 0 mm
Compatible with Apple HomeKit: no
Compatible with Google Assistant: no
Compatible with Amazon Alexa: no
IFTTT support available: no
For "harsh conditions" (according to VDE): no

Jung Schuko Socket 16 A 250V SPLS 1520 NKI WW: additional details
Protective contact® socket, alpine white with integrated increased touch protection (Safety Plus) with spring terminals for rigid and untreated flexible conductors up to 2.5 mm². Connection terminals according to DIN VDE 0620 (screw fastening, without fastening claws). The load ring is integrated into the protective measure via a grounding rail. Material: antimicrobial duroplastic. Dimensions (W x H): 70 x 70 mm.
