The MAI DZQ25/2BE-EX-E axial wall fan from Maico is a powerful ventilation fan specifically designed for use in explosion-prone areas. With a robust three-phase motor and a rated current of 0.28 A at 400 V, this fan provides a reliable solution for air supply and exhaust in demanding environments. The fan is suitable for temperatures ranging from -20 °C to +40 °C and meets the stringent safety requirements of the European Directive RL 2014/34/EU. It is explosion-proof and qualified for all gases and vapors of Ex group IIA and IIB, including hydrogen. The MAI DZQ25/2BE-EX-E features an axial impeller made of conductive plastic, which offers high impeller efficiency and enables efficient air delivery of up to 1880 m³/min. The IP 64 protection class and touch protection according to DIN EN ISO 13857 ensure additional operational safety.

• Explosion-proof according to ATEX and IECEx for zones 1 and 2
• Suitable for all gases and vapors of Ex group IIA and IIB
• Robust axial impeller made of conductive plastic
• Easy installation possible in any position
• Protective grille on the suction side for additional touch protection.
