ABB Stotz S&J Selector Switch C3SS7-10B-02

Manufacturer: ABB Stotz S&J
Description: Selector switch 3 positions 2NO black
Type: C3SS7-10B-02
Number of switching positions: 3
Actuator design: long rotary handle
Suitable for lighting: no
With light source: no
Button color: black
Hole diameter: 22 mm
Opening width: 0 mm
Opening height: 0 mm
Switching function latching: yes
Momentary: yes
Protection class (IP): IP66
Protection class (NEMA): 4X
Supply voltage: 24..240 V
Number of contacts as normally open: 2
Electrical connection design: screw connection
With front ring: yes
Material of front ring: plastic
Front ring color: black

ABB Stotz S&J Selector Switch C3SS7-10B-02: additional details
Control and signaling devices, series: Plastic Compact. An efficient solution that reduces installation time and costs. The compact series has very high dust and water resistance. The reduced number of order numbers simplifies selection and saves time. The all-in-one design allows for quick and easy installation. The following standards and approvals are met: IEC/EN 60947-1: Low-voltage switchgear and controlgear - Part 1: General rules / IEC/EN 60947-5-1: Low-voltage switchgear and controlgear - Part 5-1: Control devices and switching elements - Electromechanical control devices / IEC/EN 60947-5-5: Low-voltage switchgear and controlgear - Part 5-5: Control devices and switching elements - Electrical emergency stop device with mechanical latching function. The complete list of all technical data and standards met can be found in our product data sheets. EAN: 7320500555774.
