Product details
Specifically designed for gamers and creatives who need innovative performance, maximum bandwidth, and immense speed. The AMD X570 chipset delivers exceptional performance and allows for flexible, innovative build customizations for gamers and content creators.
Processor family | Ryzen 2nd Gen, Ryzen 3rd generation |
Memory type | DDR4-RAM |
Number of memory modules (RAM) | 4 x |
Internal connection options | S-ATA III (8x) |
Mainboard features | Front panel audio connector |
Item number | 11356754 |
Manufacturer | AsRock |
Category | Motherboards |
Manufacturer no. | 90-MXBAU0-A0UAYZ |
Release date | 7.7.2019 |
Form factor | ATX |
Socket | AM4 |
Chipset | AMD X570 |
Mainboard features | Front panel audio connector |
Operating system compatibility | Windows, Windows 10 |
BIOS type | UEFI AMI |
Processor family | Ryzen 2nd Gen, Ryzen 3rd generation |
Memory form factor | DIMM |
Number of pins | 184 x |
Number of memory modules (RAM) | 4 x |
Max. memory (RAM) | 128 GB |
Memory chip | DDR4-2666, DDR4-2933, DDR4-3000, DDR4-3200 |
Max. RAM OC | 4666 MHz |
Supported memory speed | 2133 MHz, 2400 MHz, 2933 MHz, 3200 MHz |
Memory type | DDR4-RAM |
RAM buffer | Unbuffered |
Video connections | HDMI (1x) |
Video connection version | HDMI 2.0 |
Multi-GPU technology | AMD CrossfireX, AMD Quad-GPU CrossFireX |
Network connections | RJ45 (1x) |
Ethernet controller brand | Intel |
Ethernet controller | Intel I211-AT |
Max. port speed | 1 Gbit/s |
Chip | Realtek ALC1200 |
Audio channel | 7.1 Channel |
Audio Connections | Headphone output (1x) |
Internal connection options | S-ATA III (8x) |
Expansion slot | PCI Express x16 (2x) |
PCI express version (max.) | 4 |
Number of fan connector | 3 |
USB ports | USB-A |
Power connectors | 8-pin PCI-E |
CO₂-Emission | |
Climate contribution |
Scope of delivery | SATA |
Length | 229 mm |
Width | 305 mm |
Height | 229 mm |
Weight | 1700 g |
Length | 34.50 cm |
Width | 28 cm |
Height | 7.50 cm |
Weight | 1.66 kg |
Product Safety |
