ASUS Server RS700A-E13-RS12U/2KW/12NVMe/OCP
Rack ServerOnly 3 pieces in stock at supplier
Product details
The ASUS Server RS700A-E13-RS12U/2KW/12NVMe/OCP (Model 90SF0451-M004A0) is a high-performance server designed for demanding enterprise and data center environments. It features a robust 2 kW power supply unit that ensures stable operation under heavy loads and supports up to 12 NVMe drives for exceptional storage speed and low latency. This server is equipped with an OCP network card slot, enhancing flexibility for high-speed network configurations. Built with a focus on reliability, it accommodates standard server components and is designed for efficient cooling and durability in 24/7 operation. The chassis is made from durable materials, measuring approximately 447 mm in height, 482 mm in width, and 800 mm in depth, with a weight of around 30 kg, making it suitable for installation in standard server racks. It supports the latest processor technologies and memory modules, offering scalability for virtualization, cloud computing, and big data applications. The design emphasizes easy maintenance with tool-less access to internal components and includes multiple connectivity options such as USB ports and management interfaces. This server is ideal for businesses requiring high availability, data-intensive tasks, and seamless integration into existing IT infrastructures, providing a balance of performance, energy efficiency, and long-term operational stability.
Rack height units | 1 U |
Number of processors | 2x |
Max. number of hard disks | 14 |
Item number | 62022192 |
Manufacturer | ASUS |
Category | Servers |
Manufacturer no. | 90SF0451-M004A0 |
Release date | 11.9.2025 |
Design | Rack Server |
Rack height units | 1 U |
Number of processors | 2x |
Number of processor sockets | 2x |
Memory type | DDR5 RAM |
Max. memory slots | 24 |
Max. RAM | 3072 GB |
RAM speed | 5600 MHz |
Mass storage controller type | SAS |
Max. number of hard disks | 14 |
Storage capacity | 0 GB |
Form factor | 2.5", M.2 |
Interface | SAS, SATA |
Hard disk additional functions | Hot swapping |
Expansion slot | PCI Express x16 (2x) |
PCI express version (max.) | 5 |
Internal connection options | M.2 (2x) |
USB ports | USB-A |
Exact USB ports | USB-A 3.2 Gen 1 (2x) |
Connectivity | Ethernet, LAN, USB |
Network connections | RJ45 (1x) |
Graphics card model | AST2600 |
Graphics chip (GPU) | Aspeed |
Dedicated graphics memory | 0.06 GB |
Hardware interface | PCI Express 5.0 |
Video connections | Mini DisplayPort (1x) |
Number of power supply units | 2x |
Power | 2000 W |
Input voltage | 100 - 240 V |
Max. number of power supply units | 2 |
Country of origin | China, Taiwan |
CO₂ emissions | 14,81 kg |
Climate contribution | EUR 0,37 |
Length | 483 mm |
Width | 821.70 mm |
Height | 43.20 mm |
Weight | 13.81 kg |
