Cyberpower UPS OL2200ERTXL2U Online
2200 VA, 2000 W, Online double converter UPSProduct details
The CyberPower OL2200ERTXL2U ensures high-quality power supply protection for IT devices, servers, workstations, NAS/storage devices, telecommunications equipment, network devices, security and emergency systems, as well as surveillance systems.
This UPS features an online double-conversion topology for uninterrupted power supply, with an additional ECO mode that provides an energy-saving option to reduce energy costs.
The intelligent battery management system checks the battery through internal resistance measurement, allowing it to detect aging batteries and display a replacement prompt before failure. The battery compartment design with hot-swappable battery packs enables easy maintenance without interruption of operation. This generator-compatible UPS includes the necessary emergency power off (EPO) input for security systems, allowing the UPS to be immediately de-energized in case of an emergency.
To extend battery life, the UPS utilizes Smart Battery Management (SBM).
Operating time at full load | 6.50 min |
Model | 19" rack |
Scope of application | Network cabinet, Server room |
Plug type | C20 |
Item number | 17475698 |
Manufacturer | Cyberpower |
Category | UPS |
Manufacturer no. | OL2200ERTXL2U |
Release date | 11.11.2021 |
UPS type | Online double converter UPS |
Power output | 2000 W |
Output power capacity | 2200 VA |
Model | 19" rack |
Rack Unit | 2U |
shaft type | Sine wave |
UPS protection functions | Overvoltage protection, Protection for 1000BASE-T, Protection for 100BASE-T, Protection for Modem/Fax/DSL |
Scope of application | Network cabinet, Server room |
Plug type | C20 |
Connections | RS-232, USB |
USB ports | USB-A |
Network connections | RJ45 (2x) |
Data ports | RS-232 (1x) |
Electrical safety | Due to the high power, this device requires a socket outlet fused with 16 amperes (type 23). If no suitable socket is available, the conversion must be carried out by an authorised installer. |
input voltage | 200 - 240 V |
output voltage | 200 - 240 V |
Max. input current | 11 A |
Input frequency | 40 / 70 Hz |
Output frequency | 50 - 60 Hz |
overvoltage protection | 1335 J |
Efficiency full load | 96 % |
Efficiency battery operation | 96 % |
Maximum operating temperature | 40 °C |
Operating temperature | 0 - 40 °C |
Operating humidity | 0 - 90% |
Battery category | Industry battery |
Battery | Battery |
Battery type | Lead–acid battery |
Battery size | Device specific |
Number of cells | 6 x |
Voltage | 72 V |
Charging time | 5 h |
Operating time at full load | 6.50 min |
Operating time at half load | 20 min |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | Rack mounting kit, Serial, USB cable |
Items per sales unit | 1 x |
Height | 88 mm |
Weight | 31 kg |
Width | 433 mm |
Length | 600 mm |
