Article information

• 19" server cabinet according to DIN41494
• Steel sheet housing with screwed frame, completely pre-assembled, self-ventilated, detachable
• Inside front and rear 4 x 19" profiles (2 front, 2 rear-sided), galvanised, step-less depth-adjustable
• Contrariwise numbering of rack units at the 19" profiles
• Front and rear door with 3-point turning handle (up to 24U 1-point), lockable, including profile half-cylinder according to DIN18252 / EN 1303
• Profile half-cylinder exchangeable by customer (30/10 mm)
• Door stop for front and rear door possible left- or right-sided
• Detachable side walls with 2 x latch locking (lock equal to the door lock)
• Cabinets stackable side-by-side with and without removal of the side walls, baying set available, otherwise screwable via screw set M6
• Roof and bottom with 4/6 pre-punched openings for cable entry (450 x 90 mm), for 600 mm cabinet width cable entry only rear
• Roof prepared for accommodation of 2-fan or 4-fan units, bottom with pre-punched opening for filter or cable entry modules
• Internal earthing of all cabinet sections
• Pre-assembled earthing bar rear-sided in the middle of the cabinet (ports: 20 x M5 + 2 x 8 mm)
• Max. load 1000 kg (depths 600 / 800 mm) or 1360 kg (depths 1000 / 1200 mm for >24U)
• Paint finish RAL9005, jet black
• Protection degree IP20
• Included accessories: 1 x brush, 1 x set of captive nuts (PU 20 pcs.), earthing bar and earthing cables, 4 x levelling feet M12, 2 x key
• Delivery in transport packaging on disposable pallet.
