Finder Relay module with positively driven contacts
Only 4 pieces in stock at supplier
Product details
The relay module with forced-guided contacts from Finder, model 7S.14.9.012.4220, is a highly advanced installation relay designed for safety applications. With a rated voltage of 12 V DC and a maximum switching current of 3 A, it provides reliable performance in critical environments. The module meets the requirements of standard EN 61810-3, type A, and can achieve a safety integrity level of SIL 2 in applications designed according to IEC/EN 62061. Furthermore, it is suitable for machine and plant engineering and can reach a performance level of PL d when designed according to ISO/EN 13849. The construction includes two normally open contacts and two normally closed contacts made from high-quality contact material, along with an LED status indicator for monitoring coil control. The relay module is also certified according to EN 45545-2:2013 for fire protection in railway vehicles and offers high robustness against mechanical stress and temperature variations.
- Forced-guided contacts according to EN 61810-3, type A
- Achievable safety integrity level of SIL 2
- Two normally open contacts and two normally closed contacts with 6 A switching current
- LED status indicator for coil control
- Certified according to EN 45545-2:2013 for fire protection in railway vehicles.
input voltage | 12 V |
Scope of delivery | Relay module with positively driven contacts |
Output voltage | 12 V |
Output current type | AC/DC |
Electric current output | 3 A |
Relay type | Installation relay |
Item number | 31974442 |
Manufacturer | Finder |
Category | Relays |
Manufacturer no. | 7S.14.9.012.4220 |
Release date | 24.10.2022 |
Relay type | Installation relay |
input voltage | 12 V |
Output voltage | 12 V |
Electric current output | 3 A |
Output current type | AC/DC |
Resistor | 12000 Ω (ohm) |
Switching function | Opener |
Number of openers | 2 x |
Number of closers | 2 x |
Number of poles | 2 x |
Number of switching cycles | 1 x |
Max. Switching capacity | 1.50 kW |
Manufacturer Type | 7S.14.9.012.4220 |
Smart Home | Not compatible |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | Relay module with positively driven contacts |
Length | 96 mm |
Width | 22.50 mm |
Height | 78.80 mm |
