Product details
Gigabyte AM4 motherboards support the new AMD Ryzen 3000 processors and are backward compatible with AMD Ryzen 2000 and 1000 processors. With a rich list of features, Gigabyte AM4 motherboards include Ultra Durable Armor for PCIe and memory slots, USB Type-C interfaces on select boards, refined audio quality, high-speed Ethernet, and the new standard Wi-Fi design. Gigabyte AM4 motherboards are perfect for users who want to build the best AMD platform systems.
Processor family | Ryzen 2nd Gen |
Memory type | DDR4-RAM |
Number of memory modules (RAM) | 4 x |
Internal connection options | S-ATA III (8x) |
Mainboard features | Power-On Button, Reset button, S/PDIF header, Temperature sensor connections |
Item number | 6168198 |
Manufacturer | Gigabyte |
Category | Motherboards |
Manufacturer no. | GA-AX370-GAMING K7 |
Release date | 2.3.2017 |
External links |
Form factor | ATX |
Socket | AM4 |
Chipset | AMD X370 |
Mainboard features | Power-On Button, Reset button, S/PDIF header, Temperature sensor connections |
BIOS type | UEFI AMI |
Processor family | Ryzen 2nd Gen |
Memory form factor | DIMM |
Number of pins | 288 x |
Number of memory modules (RAM) | 4 x |
Max. memory (RAM) | 64 GB |
Memory chip | DDR4-2133, DDR4-2400, DDR4-2666 |
Max. RAM OC | 3600 MHz |
Supported memory speed | 2133 MHz, 2400 MHz, 2933 MHz, 3200 MHz |
Memory type | DDR4-RAM |
RAM buffer | Error Correcting Code, Unbuffered |
Video connections | HDMI (1x) |
Video connection version | HDMI 1.4 |
Multi-GPU technology | AMD CrossfireX, AMD Quad-GPU CrossFireX, NVIDIA SLI |
Network connections | RJ45 (2x) |
Ethernet controller brand | Intel |
Ethernet controller | Intel Gbe LAN, Rivet Networks Killer E2500 |
Max. port speed | 1 Gbit/s |
Chip | ALC1220 |
Audio channel | 7.1 Channel |
Audio Connections | Jack 3.5mm (5x), Optical TOSLINK (1x) |
Internal connection options | S-ATA III (8x) |
Expansion slot | PCI Express x1 (3x), PCI Express x16 (3x) |
PCI express version (max.) | 3 |
Number of fan connector | 8 |
Power connectors | 24-pin ATX, 8-pin ATX 12V |
CO₂-Emission | |
Climate contribution |
Scope of delivery | Quick installation guide |
Length | 305 mm |
Width | 244 mm |
Length | 34.50 cm |
Width | 28 cm |
Height | 8.50 cm |
Weight | 1.62 kg |
Product Safety |
