Gigabyte Z690 UD AX
LGA 1700, Intel Z690H, ATXProduct details
The GIGABYTE Z690 UD AX is a powerful motherboard designed for the latest Intel Core i5, i7, and i9 processors. With the LGA 1700 processor socket and Intel Z690 chipset, it provides an excellent foundation for high-performance gaming and workstation setups. The motherboard supports DDR5 SDRAM with a maximum memory capacity of 128 GB, enabling high speed and efficiency in data processing. Support for various storage drive interfaces such as M.2, PCI Express 4.0, and SATA III ensures flexible storage options, while RAID support adds an extra layer of data security. With the ability for parallel processing through CrossFireX technology, the Z690 UD AX is ideal for graphics-intensive applications. Additionally, it offers modern connectivity options, including USB Type-A and Type-C, as well as integrated Wi-Fi and Bluetooth for seamless connectivity.
- Supports DDR5 SDRAM up to 6000 MHz for high performance
- Provides RAID support for enhanced data security
- Integrated Wi-Fi (Wi-Fi 6) and Bluetooth for modern connectivity
- Two PCI Express x16 expansion slots for graphics cards
- Maximum resolution of 4096 x 2304 pixels for high-resolution displays.
Processor family | Core i5, Core i7, Core i9 |
Memory type | DDR5 RAM |
Number of memory modules (RAM) | 4 x |
Internal connection options | USB 2.0 Header (4x) |
Wireless transmission | Bluetooth, Wi-Fi |
Mainboard features | Front panel audio connector |
Item number | 17541684 |
Manufacturer | Gigabyte |
Category | Motherboards |
Manufacturer no. | Z690 UD AX |
Release date | 11.11.2021 |
Form factor | ATX |
Socket | LGA 1700 |
Chipset | Intel Z690H |
Mainboard features | Front panel audio connector |
Operating system compatibility | Windows, Windows 10 |
BIOS type | UEFI AMI |
Wireless transmission | Bluetooth, Wi-Fi |
Wi-Fi standard | Wi-Fi 6 / 802.11ax |
Processor family | Core i5, Core i7, Core i9 |
Memory form factor | DIMM |
Number of pins | 288 x |
Number of memory modules (RAM) | 4 x |
Max. memory (RAM) | 128 GB |
Memory chip | DDR5 SDRAM |
Supported memory speed | 4000 MHz, 4800 MHz, 5200 MHz, 5400 MHz, 5600 MHz, 5800 MHz, 6000 MHz |
Memory type | DDR5 RAM |
RAM buffer | Error Correcting Code |
Video connections | DisplayPort (1x), HDMI (1x) |
Video connection version | HDMI 2.1 |
Multi-GPU technology | AMD Quad-GPU CrossFireX |
Network connections | RJ45 (1x) |
Ethernet controller brand | Intel |
Ethernet controller | Intel AX201 |
Chip | High Definition Audio |
Audio channel | 7.1 Channel |
Audio Connections | Headphone output (3x), Microphone |
RAID configuration | 0, 1, 10, 5 |
Internal connection options | USB 2.0 Header (4x) |
Expansion slot | PCI Express x1 (1x), PCI Express x1 (2x), PCI Express x16 (3x) |
Exact USB ports | USB-A 2.0 (2x), USB-A 3.2 Gen 1 (3x) |
Power connectors | 24-pin ATX, 4-pin ATX 12V, 8-pin ATX 12V |
CO₂-Emission | |
Climate contribution |
Scope of delivery | SATA |
Length | 244 mm |
Width | 305 mm |
Height | 70 mm |
Weight | 1000 g |
Length | 34 cm |
Width | 27 cm |
Height | 8 cm |
Weight | 1.71 kg |
