Product details
The TS-431K, supported by a 1.7 GHz quad-core processor, features 4 drive bays for secure storage of your important files and data while allowing easy file sharing with family and friends. With its compact, all-white, minimalist design, the TS-431K easily integrates into any home decor and takes up very little space. It comes with lockable drive bays that ensure the drives are not accidentally removed or dislodged, preventing data loss. The TS-431K offers comprehensive local, off-site, and cloud backups, as well as secure snapshot technology to create a reliable backup and disaster recovery plan. In the event of a system crash or accidental file deletion, you can quickly restore the system to its normal state.
File Station enables centralized file management on the NAS, connected devices, and linked clouds, making data management simpler and more time-efficient.
HBS (Hybrid Backup Sync) can back up your data and synchronize it with other NAS, servers, and cloud storage, facilitating comprehensive backup and disaster recovery.
Snapshots fully capture the system status and data, allowing you to protect files and data from accidental deletion and malware attacks.
Extensive multimedia applications and a wide range of streaming methods enhance multimedia enjoyment.
Connect external USB devices such as card readers, printers, or an uninterruptible power supply via the USB 3.2 Gen 1 port for greater application potential.
The myQNAPcloud service allows you easy access, management, and sharing of NAS files over the internet.
NAS HDD assembly | NAS Empty Enclosure |
Max. number of hard disks | 4 |
RAID configuration | 0, 1, 10, 5, 6, JBOD |
Working memory | 1 GB |
Total storage capacity | 72 TB |
Network connections | RJ45 Gigabit Ethernet (2x) |
Exact USB ports | USB-A 3.0 (3x) |
Documents | Technical data sheet.pdf |
Item number | 13019209 |
Manufacturer | QNAP |
Category | NAS |
Manufacturer no. | TS-431K |
Release date | 9.7.2020 |
Colour | White |
Exact colour description | White |
NAS HDD assembly | NAS Empty Enclosure |
Model | Desktop |
Max. number of hard disks | 4 |
Hard drive form factor | 2.5", 3.5" |
RAID configuration | 0, 1, 10, 5, 6, JBOD |
Memory type | DDR3-RAM |
Working memory | 1 GB |
Maximum possible memory | 1 GB |
Add-on packages | QNAP: Notes / Signage / Photo / Video / Multimedia / Digital TV / TV / Music / Surveillance Station, Virtualization Station, myQNAPcloud, File / Backup / HD / DJ / Download Station, Qairplay, Qsync, Print Server, HappyGet, DLNA Media Server, Antivirus, Webserver, iTunes / Mail / VPN Server |
NAS features – model-specific | AES 256-bit volume encryption |
Data storage configuration | 0 TB |
Total storage capacity | 72 TB |
Hard disk additional functions | Hot swapping |
Processor type | Alpine AL-214 |
Clock frequency | 1.70 GHz |
Number of processor cores | 2 -Core |
Network connections | RJ45 Gigabit Ethernet (2x) |
Connectivity | Ethernet, USB |
USB ports | USB-A |
Exact USB ports | USB-A 3.0 (3x) |
Internal connection options | S-ATA III (1x) |
Number of camera licenses included | 2x |
Max. number of cameras | 25x |
Power consumption | 26.70 W |
Power consumption (standby) | 11.65 W |
Number of fans | 1x |
Fan diameter | 120 mm |
Redundant power supply unit | Yes |
Country of origin | Taiwan |
Scope of delivery | 12x 2.5" HDD screws, 16x 3.5" HDD screws, 1x RJ-45 cable, Quick Installation Guide |
Length | 23.50 cm |
Width | 18 cm |
Height | 17.70 cm |
Weight | 3 kg |
Product Safety |
Length | 31.80 cm |
Width | 30.40 cm |
Height | 25.20 cm |
Weight | 3.39 kg |
