Product details
High capacity NAS with 10GbE SFP+ and 2.5 GbE, supports PCIe expansion for M.2 SSDs to accelerate applications
The quad-core 1.7 GHz TS-832PX has eight 3.5-inch SATA 6GB/s drive bays, providing enormous
The quad-core 1.7 GHz TS-832PX has eight 3.5-inch SATA 6GB/s drive bays, providing enormous
storage potential for a variety of applications and daily use. With two 10GbE SFP+ and two 2.5GbE LAN ports, the TS-832PX supports next-generation networking to enable bandwidth-intensive applications and better file access and sharing. Various PCIe cards are also supported, including QM2 cards with M.2 SATA/NVMe SSD caching, and Qtier auto-tiering storage to boost NAS performance.
Two 10GbE SFP+ and two 2.5GbE RJ45 network ports enable bandwidth-intensive tasks and accelerate file sharing.
The PCIe expansion allows the installation of a QM2 card to add M.2 SSDs for caching, a 10/5GbE network card or a wireless WLAN expansion card.
Snapshots record the system status so you can protect files and data from accidental deletion and malware attacks.
Cloud storage gateways realise hybrid cloud applications by working with the cache space reserved on the NAS to ensure low-latency data access to the cloud.
Qtier auto-tiering technology and SSD caching enable continuous storage optimisation.
Increase the storage capacity of the TS-832PX with QNAP TR RAID expansion enclosures or TL JBOD.
Two 10GbE SFP+ and two 2.5GbE RJ45 network ports enable bandwidth-intensive tasks and accelerate file sharing.
The PCIe expansion allows the installation of a QM2 card to add M.2 SSDs for caching, a 10/5GbE network card or a wireless WLAN expansion card.
Snapshots record the system status so you can protect files and data from accidental deletion and malware attacks.
Cloud storage gateways realise hybrid cloud applications by working with the cache space reserved on the NAS to ensure low-latency data access to the cloud.
Qtier auto-tiering technology and SSD caching enable continuous storage optimisation.
Increase the storage capacity of the TS-832PX with QNAP TR RAID expansion enclosures or TL JBOD.
| Max. number of hard disks | 8 |
| Memory | 4 GB |
| NAS HDD assembly | NAS Empty Enclosure |
| Total storage capacity | 0 TB |
| RAID configuration | 0, 1, 10, 5, 50, 6, 60, JBOD |
| Network connections | RJ45 2.5 Gigabit Ethernet (2x), SFP+ (2x) |
| Documents | |
| Item number | 14479984 |
| Manufacturer | |
| Category | |
| Manufacturer no. | TS-832PX-4G |
| Release date | 9.12.2020 |
| Sales rank in Category NAS | |
| External links | |
| Maximum order quantity | 2 |
| Colour group | Black |
| Exact colour description | Black |
| NAS HDD assembly | NAS Empty Enclosure |
| Model | Desktop |
| Max. number of hard disks | 8 |
| Hard drive form factor | 2.5", 3.5" |
| RAID configuration | 0, 1, 10, 5, 50, 6, 60, JBOD |
| Memory type | DDR4-RAM |
| Memory | 4 GB |
| Maximum possible memory | 16 GB |
| Data storage configuration | 0 TB |
| Total storage capacity | 0 TB |
| Hard disk additional functions | Hot swapping |
| Processor type | QNAP AL324 |
| Processor clock frequency | 1.70 GHz |
| Max. turbo clock rate | 1.70 GHz |
| Number of processor cores | 4 -Core |
| Network connections | RJ45 2.5 Gigabit Ethernet (2x), SFP+ (2x) |
| Connectivity | Ethernet |
| USB ports | USB-A |
| Internal connection options | PCI Express x2 |
| Data ports | USB |
| Power consumption | 50.86 W |
| Power consumption (standby) | 27.95 W |
| Number of fans | 3 x |
| Fan diameter | 120 mm |
| Redundant power supply unit | Yes |
| Scope of delivery | AC, Lan (RJ-45) |
| Length | 28.08 cm |
| Width | 32.93 cm |
| Height | 18.02 cm |
| Weight | 7.05 kg |
| Length | 42.50 cm |
| Width | 39 cm |
| Height | 29.50 cm |
| Weight | 8.03 kg |
Specifications may include unverified machine translations.
