The Yageo XZ pre-wired socket, angled, M8, 3-pole, PVC 5m cable XZCPV0766L5 is a pre-wired cable equipped with angled M8 sockets on both ends. It has a pole count of 3 and is 5m long. The cable features a black polyvinyl chloride (PVC) sheath. The contact base body and the contact coating are made from different materials. The cable's contact resistance is 5, the rated current is 3, and the rated voltage is 30. Additionally, it can withstand an allowable external cable temperature after installation without shock of -25. A highlight of the cable is the LED indicator, which allows for easy diagnostics and monitoring of the cable's condition.

Features:

• Pole count: 3
• Electrical connection type, field side: M8
• Type of connector, field side: Female (socket)
• Cable entry arrangement, field side: angled
• Electrical connection type, housing side: other
• Type of connector, housing side: Female (socket)
• Cable entry arrangement, housing side: other
• Cable length: 5m
• Material of cable sheath: Polyvinyl chloride (PVC)
• Halogen-free: no
• Color of cable sheath: black
• With LED indicator: yes
• Shielded: no
• Type of conductor: multi-core
• Cross-linked: no
• Material of contact base body: other
• Material of contact coating: other
• Allowable external cable temperature after installation without shock: -25
• Rated current: 3
• Rated voltage: 30
• Contact resistance: 5
• Protection class (IP): other
• Allowable external cable temperature during installation/handling: -.
