Turck Magnetic field sensor
Product details
The Turck magnetic field sensor BIM-NST-AN6X-H1141/S34 is a highly advanced sensor specifically designed for use in pneumatic cylinders. It features a magnetic field-resistant construction and is made from durable PA12-GF30 plastic. With an NPN output and a nominal voltage of 10 to 30 VDC, this sensor provides reliable performance in industrial applications. It is suitable for use in demanding environments, as it is resistant to welding fields of 50 to 60 Hz. Additionally, it meets the IP67 protection class, making it resistant to dust and water. The magnetic field sensor is equipped with an M12 x 1 connector, which facilitates installation and integration into existing systems. Its compact design, with dimensions of 17 mm in width, 14 mm in height, and 28 mm in length, makes it versatile for various applications.
- Magnetic field-resistant sensor for pneumatic cylinders
- IP67 protection class for high environmental resistance
- NPN output for easy integration into control systems
- Durable material made from PA12-GF30 plastic
- Acoustic feedback as an additional feature.
Width | 17 mm |
Item number | 36809638 |
Manufacturer | Turck |
Category | Buttons + Switches |
Manufacturer no. | 4685501 |
Release date | 28.6.2023 |
Material group | Plastic |
Material | Plastic |
LED colour | without LED |
Number of poles | 1 x |
Nominal voltage | 30 V |
Nominal current | 30 A |
Protection type (IP code) | IP67 |
Switch + push-button Additional function | Acoustic feedback |
Country of origin | Germany, Poland |
CO₂-Emission | |
Climate contribution |
Smart Home | Not compatible |
Items per sales unit | 1 Piece |
Scope of delivery | Magnetic field sensor |
Length | 28 mm |
Width | 17 mm |
Height | 14 mm |
