The Turck opto-sensor is a high-precision laser measurement system designed for a variety of applications in automation technology. With a 2-line, 8-segment display, it allows for easy readability of measurement values. The sensor is equipped with a robust PVC cable and offers flexible installation thanks to the M12 x 1, 5-pin connector. It operates with a supply voltage of 12 to 30 VDC and features switchable PNP/NPN switching outputs as well as an analog output of 4 to 20 mA. The sensor's range extends from 100 to 400 mm, providing a high resolution of less than 0.02 mm at distances of 100 mm to 250 mm. The opto-sensor meets the requirements of laser class 2 and is certified according to IEC 60825-1:2007, making it a safe choice for industrial applications.

• Protection class IP67 for high resistance to dust and water
• Acoustic feedback to confirm switching operations
• High resolution of < 0.02 mm at short distances
• Switchable PNP/NPN outputs for flexible applications
• Robust plastic construction for industrial use.
