Wago Female connector
Minimum order 10Price in EUR including VAT
free shipping
WAGO GmbH & Co. KG female connector 731-518/031-000. Manufacturer: WAGO GmbH & Co. KG. Designation: Female connector, 18-pin, 5mm. Type: 731-518/031-000. Connection type: PCB to cable. Contact design: Socket. Number of poles: 18. Number of rows of plug contacts: 1. Contact pitch: 5 mm. Terminal pitch: 5 mm. Angle contact/conductor connection: 135° (angled upwards). Rated current: 12 A. Rated voltage: 320 V. Rated impulse voltage: 4 kV. Overvoltage category: III. Pollution degree: 2. Connectable conductor cross-section flexible without ferrule: 0.08 to 2.5 mm². Connectable fine-stranded conductor cross-section with ferrule: 0.25 to 1.5 mm². Connectable solid conductor cross-section: 0.08 to 2.5 mm². Connectable conductor cross-section stranded: 0.08 to 2.5 mm². Electrical connection type: spring-loaded connection. Connectable cable type: round cable. Material of contact coating: tin. Material of contact: other copper alloys. Material of insulating body: thermoplastic. Material of housing: plastic. Coating of housing: uncoated. Housing colour: grey. Flammability class of insulating material according to UL 94: V0. With protective conductor: no. Operating temperature: -60 to 85 °C. Protection class (IP), mounted: IP20. WAGO GmbH & Co. KG female connector 731-518/031-000: further details include a 1-conductor female connector, angled CAGE CLAMP® 2.5 mm², spacing 5 mm, 18-pole, mounting flange TS 35/surface mounting, 2.50 mm² grey.
Cable + connector type | Plug connectors |
Cable length | 0.01 m |
Item number | 36754699 |
Manufacturer | Wago |
Category | Cables + Plugs |
Manufacturer no. | 731-518/031-000 |
Release date | 28.6.2023 |
Minimum order | 10 |
Order quantity steps | 10 |
Colour | Grey |
Material group | Plastic |
Material | PA 66 |
Cable + connector type | Plug connectors |
Compatible hardware | Various |
Max. temperature | 85 °C |
Min. temperature | -60 °C |
Cable length | 0.01 m |
Manufacturer Type | 031-000, 731-518 |
Connectors Design | Socket, horizontal installation |
Number of cores | 18 x |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Items per sales unit | 10 Piece |
Scope of delivery | Female connector 18-pin 5mm |
Length | 1.31 cm |
Width | 10.48 cm |
Height | 2.30 cm |
