Nebula Cloud-managed Layer 3 Enterprise Switch

The XGS2220 Series is a family of Layer 3 access switches that consists of six models, including PoE, non-PoE, and fiber options. Non-PoE models offer Gigabit desktop ports for everyday network access; PoE models provide flexible options with larger PoE budgets and a mix of 60 W and 30 W ports to power devices like the latest WiFi 6/6E wireless access points. The fiber model aims to achieve business connectivity for high fiber port density requirements.

Flexible 10G for converged networking applications

In addition to four 10G SFP+ uplinks, the XGS2220 Series includes two additional 10G Multi-Gig RJ45 ports, offering the flexibility to connect to servers, network storage, or other high-speed network devices. Businesses can operate smoothly with better extensibility and a robust network infrastructure.

Multiple power budget options

PoE models come with 10 ports of PoE++ (IEEE 802.3bt) offering up to 60 W per port and 16-40 ports of PoE+ (IEEE 802.3at) delivering up to 30 W per port to meet a variety of applications, including the latest generation of wireless access points.

Within the range, the three PoE models of 30HP, 54HP, and 54FP can offer larger power budgets of 400 W, 600 W, and 960 W respectively, allowing flexibility in powering a full range of PoE devices efficiently for applications like VoIP, surveillance, high-density networked AV applications, and Zyxel’s comprehensive WiFi 6/6E AP portfolio.

Nebula, manage it your way!

The support of NebulaFlex Pro allows you to easily switch management modes between standalone management and intuitive Nebula cloud-managed mode with a 1-year Pro Pack bundled. Nebula provides both an intuitive web interface and a mobile app to deliver a streamlined experience for installation and management of your network, without additional cost for software or hardware controllers.
