Best selling Buttons + Switches from Busch-Jaeger
On this page you'll find a ranking of the best Busch-Jaeger products in this category. To give you a quick overview, we've already ranked the most important information about the products for you.
1. Busch-Jaeger SD/U12.63.11-825
Busch-Trevion® Displays 2.4, in format 63 for switch programs such as axcent, Solo, future. Freely programmable touch panel with a 2.4-inch IPS screen with a resolution of 240 x 240, enabling control and monitoring of the free@home or KNX system. Control, observe, and manage your entire installation on one device: switching, dimming, sliders, blinds, RGBW controls, step switches, scene switches, display elements, audio controls. The display includes a brightness and proximity sensor. Operation is supported by haptic feedback. The display features an integrated temperature controller (RTC) with a built-in temperature sensor. An optional remote sensor for temperature measurement can be connected to the rear input. An additional 24VDC power supply is required for operation.
KNX: Up to 12 control pages with up to 12 control elements can be created. A maximum of 1 to 4 touch surfaces is possible per page. 10 scene actuators, 10 logic functions, 10 presence simulations, and time programs, as well as 18 fault and alarm messages. The primary function allows direct operation of a function when touching the display. The rear input can alternatively be used as a binary input instead of the remote sensor.
free@home: Up to 16 control functions can be created on up to 4 pages. A maximum of 4 touch surfaces is possible per page. The scene function, logic functions, presence simulation, and time programs are provided by the system access point in free@home and are not additionally required on the display. Fault and alarm messages are displayed as pop-ups. The rear input can be used to connect a remote sensor.
2. Busch-Jaeger Grossverpackung 100er 2000/6 US BULK Wippschalter-Einsatz
The Busch-Jaeger BJ 2000/6 US BULK rocker switch insert is a practical solution for single-pole and three-way switching in various electrical installations. This bulk package contains 100 pieces of the rocker switch insert, known for its high quality and durability. Made in Germany, these switches are suitable for a variety of platforms, including Busch-Duro 2000® SI, Reflex SI, and many other models. The insert is made from robust plastic and offers reliable performance with a maximum current rating of 10 A. These rocker switches are ideal for use in residential and commercial buildings, ensuring easy and safe operation.
- Suitable for single-pole and three-way switching
- Compatible with various platforms such as Busch-Duro 2000® SI and Reflex SI
- Maximum current rating of 10 A
- Made from high-quality plastic
- Delivered in a convenient bulk package with 100 pieces.
3. Busch-Jaeger APWG ocean Light signal 2661W-54 E10 without bonnet alpine white
The APWG ocean light signal 2661W-54 E10 without cover in alpine white from Busch-Jaeger is a functional and versatile light signal that is ideal for various applications. It is equipped with screw terminals that allow for easy installation. This light signal is available without a cover and lamp, making it a flexible solution for individual lighting needs. The product is designed for indoor use and can achieve an IP44 protection rating when used with appropriate covers. It offers the option to work with a label holder that can be illuminated to ensure clear labeling. The light signal is compatible with E10 lamps, allowing for easy adaptation to different lighting requirements.
- E10 thread for easy lamp installation
- Compatible with various E10 lamp models
- Illuminable label holder for custom labeling
- IP44 protection rating only in conjunction with covers
- Easy installation via screw terminals.
Buttons + Switches
EUR21,83
Busch-Jaeger APWG ocean Light signal 2661W-54 E10 without bonnet alpine white
4. Busch-Jaeger Changeover switch
Busch-Jaeger Switch 2000/6 UJ/05
Manufacturer: Busch-Jaeger
Description: Switch with drilling option for fan switch
Type: 2000/6 UJ/05
Switching type: Toggle switch
Operation type: Rocker/button
Composition: Basic element with central cover plate
Push button: no
Number of operating rockers: 1
Mounting type: Flush-mounted
Mounting method: Claw/screw fastening
With mounting plate: yes
Material: Plastic
Material quality: Thermoplastic
Halogen-free: yes
Antibacterial treatment: no
Surface protection: untreated
Surface finish: glossy
Color: other
Text field/labeling area: no
Lighting: no
Lighting function: other
Suitable for protection class (IP): IP20
Nominal voltage: 250 V
Rated current: 10 A
Switching current for fluorescent lamps: 10 AX
Feedback contact: no
Connection type: Plug terminal
Heater switch: no
Washing machine switch: no
Device width: 91 mm
Device height: 91 mm
Device depth: 32 mm
Installation depth: 25 mm
Min. depth of device box: 25 mm
Compatible with Apple HomeKit: no
Compatible with Google Assistant: no
Compatible with Amazon Alexa: no
IFTTT support available: no
Busch-Jaeger Switch 2000/6 UJ/05: additional details UP switch complete set. Consisting of switch insert, rocker, and cover frame. For installation in standard flush-mounted device boxes according to DIN 49073. Compatible with item numbers: 1722-281, 1723-281, 1724-281, and 1725-281.
5. Busch-Jaeger Rocker, shutter push-button 2CKA001731A2021
Busch-Jaeger rocker platinum 2505 JA/02-212
Manufacturer: Busch-Jaeger
Designation: Rocker platinum blind push-button KNX
Type: 2505 JA/02-212
Imprint/marking: Symbol "arrows"
Use: Blind
Suitable for bus system push-button coupling: No
Mounting type: Clamp/screw mounting
Material: Plastic
Material quality: Thermoplastic
Halogen-free: Yes
Surface protection: Untreated
Finish: Glossy
Antibacterial treatment: No
Colour: White
RAL number (similar): 1013
With labelling field: No
With replaceable lens/symbol: No
Suitable for protection class (IP): IP20
Further details: As cover for flush-mounted series switches, changeover/changeover switches, and double push-buttons. As cover for flush-mounted blind switches/push-buttons.
EAN: 4011395193129.
6. Busch-Jaeger Rocker control switch
The rocker control switch from Busch-Jaeger is a versatile and functional product designed for controlling electrical consumers. With an integrated LED, this switch provides visual feedback on the operational status. It is suitable for installation in flush-mounted boxes according to DIN 49073 and fits various platforms such as Busch-art linear®, future® linear, and Busch-axcent®. The switch is made from high-quality plastic and features a robust construction that ensures a long lifespan. With a rated current of 10 Amperes and a rated voltage of 250 Volts, it is suitable for most applications in residential and commercial settings. The rocker control switch is available in the color blue and offers easy operation through its rocking function.
- Integrated LED for visual feedback
- Suitable for flush mounting according to DIN 49073
- Compatible with various platforms from Busch-Jaeger
- Robust construction made of high-quality plastic.
7. Busch-Jaeger Series switch insert
Suitable for Impuls central plate with push button. Can only be installed in conjunction with standard flush-mounted device boxes according to DIN 49073 or Busch-Jaeger Art. No. 3040 flush-mounted box for masonry, 3050 flush-mounted box for hollow walls, or 3060 flush-mounted box for concrete. Lamp for replacement needs 8360, 8362, 8363, and LED inserts. When used with LED lights or low-power energy-saving lamps, self-ignition may occur (light bulbs and/or the Impuls Aura lighting may flicker). Solution: Use compensator 6596 in parallel with the load.
Type: 2001/5 U
Mechanical switches / push button inserts pressure sequence switch insert series connection.
8. Busch-Jaeger 2000/6 USK (2000/6USK)
The Busch-Jaeger rocker control switch 2000/6 USK is a versatile switch insert designed for on/off and toggle switching. With an integrated pilot light, it provides both control and orientation functions. The switch is suitable for flush mounting and is made from high-quality halogen-free duroplastic. The matte surface offers an appealing look, while the plug terminals allow for easy installation. The rocker control switch is rated for a nominal voltage of 250 V and a rated current of 10 A, making it a reliable choice for various applications. With a compact design and a mounting depth of only 25 mm, it fits standard device boxes. The switch is not compatible with smart home systems but is excellent for traditional installations.
- Integrated pilot light for control and orientation functions
- Suitable for on/off and toggle switching with N terminal
- Made from halogen-free duroplastic
- Easy installation with plug terminals
- Matte surface for an attractive design.
9. Busch-Jaeger Control switch 2-pin 2000/2UK 2000/2UK (1022-0-0656)
The Busch-Jaeger control switch 2-pole 2000/2UK is a high-quality rocker control switch designed for flush mounting. It provides a reliable way to control electrical devices and is equipped with an integrated pilot light that offers visual feedback on the operating status. The switch is made of durable thermoplastic, making it robust and long-lasting. With a rated voltage of 250 V and a rated current of 10 A, it is suitable for a variety of applications. The rear connection is made via a terminal block, allowing for easy installation. The switch features a matte blue finish, blending harmoniously into various living and working environments. It is not only functional but also aesthetically pleasing, providing a practical solution for controlling lighting and other electrical devices.
- Integrated pilot light for visual feedback
- Rear connection with terminal block for easy installation
- Made from robust thermoplastic
- Suitable for flush mounting
- Rated current of 10 A and rated voltage of 250 V.
10. Busch-Jaeger Rocker switch off and on 2CKA001042A0993
The rocker switch for on/off and changeover 2CKA001042A0993 from Busch-Jaeger is a functional and reliable product designed for controlling electrical consumers. With a clear and modern design, this switch seamlessly integrates into various residential and work environments. The switch is part of the Busch-Duro 2000® AP series and offers user-friendly operation through its rocking mechanism. The integrated labeling field allows for individual marking, making it easier to use in more complex circuits. Made in Germany, this rocker switch stands for quality and durability. It is not compatible with smart home systems but provides a simple and effective solution for manual control of lighting and other electrical devices.
- Integrated labeling field for individual marking
- Part of the Busch-Duro 2000® AP series
- Made in Germany for high quality and durability.
