Best selling Network antenna from Quwireless
On this page you'll find a ranking of the best Quwireless products in this category. To give you a quick overview, we've already ranked the most important information about the products for you.
1. Quwireless QuMax directional for RUTX50
Integrated multi-band LTE and 5G panel antenna with Wi-Fi omni antenna, GPS, and a place to install Teltonika RUTX50 (all-in-one).
QuMax for RUTX50 is a high-performance directional antenna designed for various wireless communication applications. This all-in-one product consists of multi-band 5G, Wi-Fi, and GPS antennas integrated in an IP67 enclosure. It offers 7.5 dBi gain and wide beamwidth, making it suitable for both urban and rural environments.
Combining QuMax with RUTX50 inside the antenna housing provides a complete outdoor solution with multiple use scenarios such as public transportation, energy, mining, IoT, and more.
5G / LTE antenna specification:
Frequency:
- 0.617 - 0.96 GHz
- 1.7 - 2.7 GHz
- 3.3 - 4.6 GHz
- 4.7 - 6.0 GHz
Gain:
- 0.617 - 0.96 GHz: 6 dBi
- 1.7 - 2.7 GHz: 7 dBi
- 3.3 - 4.6 GHz: 7 dBi
- 4.7 - 6.0 GHz: 5.5 dBi
Supported LTE bands:
- 1, 2, 3, 4, 5, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 22, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 46, 47, 48, 49, 52, 53, 65, 66, 67, 68, 69, 71, 85, 103, 106
Supported 5G bands:
- n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n34, n38, n39, n40, n41, n46, n47, n48, n53, n65, n66, n67, n71, n77, n78, n80, n81, n82, n83, n84, n85, n86, n89, n90, n95, n97, n98, n100, n101, n256
VSWR:
- <2.00, max <3.00
Beamwidth:
- 80°/80° ±15°
Polarization:
- X (+-45 degrees)
Impedance:
- 50 Ω
Wi-Fi antenna specification:
Frequency:
- 2.40 - 2.50 GHz
- 5.0 - 7.125 GHz
Gain:
- 2.40 - 2.50 GHz: 6 dBi
- 5.0 - 7.125 GHz: 7.5 dBi
VSWR:
- <1.70, max <2.00
Beamwidth:
- 360°/25° ±5°
Polarization:
- Vertical
Impedance:
- 50 Ω
Mechanical specification:
Materials:
- ABS, aluminum, PTFE, fiberglass
Connector type:
- RJ45
Ingress protection:
- IP67
Dimensions:
- 486.0 x 292.2 x 105.6 mm
- 19.13 x 11.50 x 4.16 inches
Weight:
- 2.8 kg
- 6.17 lbs
Operating temperature:
- From -40°C to 80°C.
2. Quwireless QuSpot for RUTX50
Integrated outdoor multi-band high-performance LTE omni antenna GPS antenna for installation with Teltonika RUTX50 (all-in-one) up to 4 dBi LTE antenna gain IP67 passive PoE support. The integrated multi-band LTE and 5G omni antenna, Wi-Fi omni antenna, and GPS installation for Teltonika RUTX50 (all-in-one) QuSpot for RUTX50 is an outdoor antenna that provides a reliable wireless connection in a variety of environments. This product is an all-in-one solution that combines a high-gain omnidirectional 5G and Wi-Fi antenna with the RUTX50 in a single IP67 enclosure. This integration enables the implementation of new RUTX50 solutions for outdoor use. QuSpot for RUTX50 is an ideal solution for outdoor wireless connectivity in mobile applications such as transportation, yachting, boats, and camping, as well as in urban centers with high signal density.
3. Quwireless AP5G4-G - QuPanel 5GLTE Global MIMO 4x4, 5m
Directional ultra wideband 5G/LTE MIMO 4x4 antenna
The QuPanel 5G/LTE directional MIMO 4x4 is an ultra wideband 5G outdoor antenna. It is primarily designed for LTE/5G/3G/2G devices that require high-efficiency connections. The antenna covers many LTE bands, including the new Extended LTE Band 71, and frequencies from 600 to 6000 MHz. The mounting bracket allows the antenna to be installed on a pole or wall, enabling client devices to receive Internet via LTE/5G/3G/2G. It is an ideal solution for use with all industrial and domestic 4x4 5G modems and routers.
5G / LTE Antenna Specification
Frequency
- 617 - 960 MHz
- 1.7 - 2.7 GHz
- 3.3 - 4.6 GHz
- 4.7 - 6.0 GHz
Gain
- 617 - 960 MHz: 6 dBi
- 1.7 - 2.7 GHz: 7 dBi
- 3.3 - 4.6 GHz: 7 dBi
- 4.7 - 6.0 GHz: 5.5 dBi
Supported LTE Bands
- 1, 2, 3, 4, 5, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 22, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 46, 47, 48, 49, 52, 53, 65, 66, 67, 68, 69, 71, 85, 103, 106
Supported 5G Bands
- n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n34, n38, n39, n40, n41, n46, n47, n48, n53, n65, n66, n67, n71, n77, n78, n79, n80, n81, n82, n83, n84, n85, n86, n89, n90, n95, n97, n98, n100, n101, n256
VSWR
- <2.00, max <3.00
Beamwidth
- 80°/80° ±15°
Polarization
- X (±45 degrees)
Impedance
- 50 Ω
Mechanical Specification
Materials
- ABS, aluminum, PTFE, fiberglass
Connector Type
- SMA
Ingress Protection
- IP67
Dimensions
- 486.0 x 292.2 x 105.6 mm
- 19.13 x 11.50 x 4.16 inch
Weight
- 2.8 kg
- 6.17 lbs
Operating Temperature
- From -40°C to 80°C
- From -40°F to 176°F
Mast Diameter
- 25-60 mm
- 0.98-2.36 inch.
4. Quwireless Antenna QuOmni 5G/LTE Global
Omnidirectional ultra wideband 5G/LTE MIMO 4x4 antenna
The QuOmni 5G/LTE omnidirectional MIMO 4x4 is an ultra wideband LTE outdoor antenna. It is primarily designed for LTE, 5G, 3G, and 2G devices that require high-efficiency connections. The antenna covers many LTE bands, including the new extended LTE Band 71, with frequencies ranging from 617 to 6000 MHz. The mounting bracket allows the antenna to be installed on buildings (on a pole or wall) or on moving points like trains, buses, lorries, yachts, and boats to receive internet via LTE, 5G, 3G, or 2G. It is an ideal solution for use with all industrial and domestic 4x4 LTE modems and routers such as Teltonika, DIGI, Mikrotik, Robustel, and Cisco.
5G / LTE Antenna Specification
Frequency
- 617 - 960 MHz
- 1.7 - 2.7 GHz
- 3.3 - 4.7 GHz
- 5.2 - 6.0 GHz
Gain
- 617 - 960 MHz: 3 dBi
- 1.7 - 2.2 GHz: 4 dBi
- 3.3 - 4.7 GHz: 4.5 dBi
- 5.2 - 6.0 GHz: 2.5 dBi
Supported LTE Bands
- 1, 2, 3, 4, 5, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 22, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 47, 48, 49, 52, 53, 65, 66, 67, 68, 69, 71, 85, 103, 106
Supported 5G Bands
- n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n34, n38, n39, n40, n41, n47, n48, n53, n65, n66, n67, n71, n77, n78, n80, n81, n82, n83, n84, n85, n86, n89, n90, n95, n97, n98, n100, n101, n256
VSWR
- <1.80, max <2.00
Beamwidth
- 360°/35° ±5°
Polarization
- Vertical
Impedance
- 50 Ω
Mechanical Specification
Materials
- ABS, aluminum, PTFE
Connector Type
- SMA
Ingress Protection
- IP67
Dimensions
- 160 x 160 x 240 mm
- 6.3 x 6.3 x 9.45 inch
Weight
- 1.5 kg
- 3.31 lbs
Operating Temperature
- From -40°C to 80°C
- From -40°F to 176°F
Mast Diameter
- 40-60 mm
- 1.57-2.36 inch.
5. Quwireless QuMax for Teltonika RUTX12/14
AX12M - QuMax for Teltonika RUTX12/14
The QuMax MIMO 4x4 directional LTE antenna (4x SMA connector for 2x embedded LTE modems) for Teltonika RUTX12/14 routers is a perfect outdoor device for mobile and fixed installations such as industrial, CCTV, hotspots, etc. It also features embedded Wi-Fi dual band 2.4 & 5 GHz omni antennas, a GPS antenna, and a Bluetooth antenna. It is designed to have the Teltonika RUTX12/14 router installed inside an IP67 enclosure. Using the RUTX12/14 with a QuMax antenna provides an integrated complete solution with an embedded router and multi-band antennas in one enclosure.
LTE Antenna Specifications
- Frequency: 0.694 - 0.96 GHz; 1.7 - 2.2 GHz; 2.2 - 2.7 GHz
- Supported LTE/5G bands: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 23, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 44, 53, 59, 62, 65, 66, 67, 68, 69, 85, n80, n81, n82, n83, n84, n86, n89, n90, n95
- Gain: 0.694 - 0.96 GHz: 4 dBi; 1.7 - 2.2 GHz: 5 dBi; 2.2 - 2.7 GHz: 6 dBi
- Front-to-back: >8 dB
- VSWR:
- Beam width: 90°/90° +/-30°
- Polarization: Vertical
- Impedance: 50 ohms
Wi-Fi Antenna Specification
- Frequency: 2.40 - 2.50 GHz; 4.70 - 6.00 GHz
- Gain: 2.40 - 2.50 GHz: 6 dBi; 4.70 - 6.00 GHz: 7 dBi
- VSWR:
- Beam width: 360°/25° +/-5°
- Polarization: Vertical
- Impedance: 50 ohms
Bluetooth Antenna Specifications
- Frequency: 2.30 - 2.60 GHz
- Gain: 3 dBi
- VSWR:
- Beam width: 360°/25° +/-5°
- Polarization: Vertical
- Impedance: 50 ohms
Mechanical Specification
- Materials: ABS, aluminum, PTFE, fiberglass
- Connector type: RJ45
- Ingress protection: IP67
- Dimensions: 392 x 392 x 99 mm (15.43 x 15.43 x 3.90 inch)
- Weight: 3.7 kg (8.16 lbs.)
- Operating temperature: From -40°C to 75°C (from -40°F to 167°F).
6. Quwireless WIBOX SA MDB255-90-14X - 2.5 & 5 GHz Dual Band Antenna
The WIBOX SA MDB255-90-14X is a powerful dual-band MIMO 2x2 sector antenna that operates in both the 2.5 GHz and 5 GHz ranges. It offers a high gain of 12 dBi in the frequency range of 2.35 to 2.65 GHz and 14 dBi in the range of 5.1 to 5.85 GHz. This antenna is ideal for point-to-multipoint topologies and is excellent for covering medium areas, such as hotspots in schools, halls, stadiums, or other public places. It can be installed both indoors and outdoors and is IP67 waterproof, making it particularly robust against various weather conditions. The WIBOX SA MDB255-90-14X is compatible with a wide range of systems, including Wi-Fi, WiMAX, LTE, Bluetooth, ISM, and RFiD, making it a versatile solution for network connections.
- Dual-band MIMO 2x2 sector antenna with 12 dBi and 14 dBi gain
- Suitable for point-to-multipoint connections in medium areas
- IP67 certified for indoor and outdoor use
- Compatible with Wi-Fi, WiMAX, LTE, Bluetooth, ISM, and RFiD
- Integrated, weatherproof WiBOX Medium housing for the installation of radio devices.
7. Quwireless AP5G4 - QuPanel 5G/LTE MIMO 4x4, 5 m Cable
AP5G4 - QuPanel 5G/LTE MIMO 4x4, 5 m Cable
The QuPanel 5G/LTE directional MIMO 4x4 high gain antenna is designed primarily for 5G and 4G LTE, but it is also compatible with 3G and 2G networks. This antenna enhances signal strength in rural and suburban areas, as well as in locations with weak mobile signals. It is intended for installation on buildings, either on a pole or a wall. With a very wide working frequency range, the antenna serves as a universal client for the 5G bands n77 and n78, as well as LTE bands including 700, 800, 1800, 1900, 2100, 2300, 2600, 3400, and 3800 MHz. It is compatible with Teltonika and other MIMO 4x4 5G/LTE/3G/2G modems and routers.
5G/LTE Antenna Specifications
- Frequency: 0.694 - 0.96 GHz; 1.7 - 2.2 GHz; 2.2 - 2.7 GHz; 3.3 - 3.8 GHz
- Supported LTE/5G bands: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 22, 23, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 48, 49, 52, 53, 59, 62, 65, 66, 67, 68, 69, 85, n78, n80, n81, n82, n83, n84, n86, n89, n90, n95
- Gain: 0.694 - 0.96 GHz: 7 dBi; 1.7 - 2.2 GHz: 7 dBi; 2.2 - 2.7 GHz: 7.5 dBi; 3.3 - 3.8 GHz: 5.5 dBi
- Front-to-back: 0.694 - 0.96 GHz: > 10 dB; 1.7 - 2.2 GHz: > 12 dB; 2.2 - 2.7 GHz: > 14 dB; 3.3 - 3.8 GHz: > 17 dB
- VSWR: < 1.70, max. < 2.00
- Beam width: 70°/70° +/- 15°
- Polarization: Dual polarized X-pol
- Impedance: 50 ohms
Mechanical Specification
- Materials: ABS, aluminum, PTFE, fiberglass
- Ingress protection: IP67
- Dimensions: 392 x 392 x 99 mm (15.43 x 15.43 x 3.90 inch)
- Weight: 3.7 kg (8.16 lbs.)
- Operating temperature: From -40°C to 75°C (from -40°F to 167°F)
- Cable length: 5 m
- Cable type: LMR195 white
- Connector type: 4x SMA plug.
8. Quwireless WiBOX SA M3DBC245-120-8V 3x 8 dBi 2,4 - 2,50 GHz and 3x 7 dBi ±1 dBi 4.60-6.40 G
The Wireless Instruments 3-Element MIMO 3x3 2.4/5 GHz Dual-Band Antenna for Wi-Fi is a robust and powerful panel designed for both outdoor and indoor applications. The WiBOX SA M3DBC245-120-8V is a 3-element patch antenna primarily intended for high-density installations where high gain and wide radiation patterns are required. The system offers relatively high gain with a wide horizontal beam and a low front-to-back ratio, making it a unique solution on the market. The antenna is designed to operate with 2.4 GHz/5 GHz access points and provides IP67 rating for the entire system, along with 3 RP-SMA/U.FL/MMCX pigtails in the installation box. The antenna is integrated into the WiBOX Medium housing from Wireless Instruments, which offers a compartment for electronic devices. The included WiMount mounting system allows for wall or mast installation.
Electrical Data
- Frequency: 2.4 - 2.5 GHz, 4.6 - 6.4 GHz
- Gain: 8 dBi, 7 dBi ±1
- VSWR: 25 dB
- Front-to-Back: >20 dB
- Impedance: 50 Ω
- Maximum Input Power: 20 W
- Lightning Protection: No
- DC Ground: Yes
Mechanical Specifications
- Material: ABS
- External Dimensions: 27.2 x 27.6 x 9.6 cm
- Connectors: RJ45 and 1xSMA/SMA RP/TNC RP/MMCX
- Weight: 1.8 kg
- Operating Temperature: from -40°C to 80°C
Mounting Kit
- Dimensions: 9.9 x 10.5 x 14.8 cm
- Adjustment Range: +/- 30°
- Weight: 0.87 kg
- Mast Dimensions: Range 25 - 65 mm
- Material: Polyamide with fiberglass + galvanized steel brackets.
Network antenna
EUR209,–
Quwireless WiBOX SA M3DBC245-120-8V 3x 8 dBi 2,4 - 2,50 GHz and 3x 7 dBi ±1 dBi 4.60-6.40 G
Wi-Fi
9. Quwireless WISECTOR PRO M3-90-16HV - 3.3 - 3.8 GHz Sector Antenna for Cambium PMP 450
WiSector PRO M3-90-16HV - 3.3 - 3.8 GHz Sector Antenna for Cambium PMP 450
The WiSector PRO M3-90-16HV for Cambium PMP 450 is a dual-polarity sector antenna. It features a dual-polarized H and V antenna with a frequency range of 3.3 - 3.8 GHz and a beamwidth of 90 degrees. The antenna is designed for establishing medium-range outdoor connections. The set includes a robust mounting system made of high-quality stainless steel, intended for PMP450 Cambium models. The WiSector comes with two SMA connectors located at the bottom of the housing. The connectors are surrounded by a special collar that protects them from water. Thanks to the PTFE material used for the circuit board, the WiSector PRO M3-90-16HV has better performance characteristics than other antennas available on the market.
Features:
- 2x 16 dBi gain
- H and V polarization for the frequency of 3300 - 3800 MHz
- 2 SMA connectors
- Large, ergonomic, and voluminous WiSector PRO housing for the installation of radio equipment
- Waterproof outdoor housing
- Designed for all weather conditions
Applications:
- Point-to-Multipoint connections
- Hotspot
Compatible with:
- Cambium Networks - PMP 450
Electrical Properties:
- Frequency: 3.3 - 3.8 GHz
- Gain: 16 dBi
- VSWR:
- Beamwidth: 90°/9°
- Polarization: H and V
- Cross-polar isolation
- Front-to-Back: > 25 dB
- Isolation between ports: > 32 dB
- Impedance: 50 Ohm
- Max input power: 50 W
- Lightning protection: No
- DC grounding: No
Mechanical Properties:
- Dimensions: 12 x 44.5 x 5.5 cm
- Weight: 3.5 kg
- Connector: 2 x SMA connectors
- Material: PET
- Waterproof rating: IP67
- Operating temperature: from -40 °C to +70 °C.
Network antenna
EUR339,–
Quwireless WISECTOR PRO M3-90-16HV - 3.3 - 3.8 GHz Sector Antenna for Cambium PMP 450
10. Quwireless WIBOX PA M5-24X - 5 GHz, 24 dBi PtP/Client Antenna
Wireless Instruments WIBOX PA M5-24X - 5 GHz, 24 dBi PtP/Client Antenna
The WiBOX PA M5-24X is an innovative, PTFE microstrip, dual polarity X (slant) polarized (MIMO 2x2) planar antenna operating in the frequency range of 5.1 - 5.95 GHz with 24 dBi gain in both polarizations. It is designed for point-to-point (PtP) or point-to-multipoint (PtMP) applications as a client antenna, where high-gain antennas are required. Due to the slant (+/- 45°) polarization, the PA M5-24X can be used in interfered environments. It is compatible with WLAN 802.11n/ac systems and can be installed indoors and outdoors (IP67). The antenna is integrated into the high-quality WiBOX Large box system.
Features:
- 2x 24 dBi gain
- X polarization for the frequency of 5100 - 5950 MHz
- 2x SMA female connectors
- Large, ergonomic WiBOX Large enclosure for radio equipment installation
- Outdoor waterproof enclosure
- Designed for and resistant to all weather conditions
- RJ45 waterproof system
- Grounding system protecting against lightning - DC ground systems
- WLAN - 5 GHz
- WiMAX - 5 GHz
- ISM - 5725 - 5875 MHz
- RFiD - 5725 - 5875 MHz
Applications:
- System integration
- Point-to-point connections
- Point-to-multipoint connections
Compatible with:
- Cambium Networks - ePMP 1000 Connectorized Radio, ePMP 1000 GPS Sync Radio
Electrical Specifications:
- Frequency: 5.1 - 5.95 GHz
- Gain: 24 dBi
- VSWR:
- Beamwidth: 8°/8°
- Polarization: X
- Cross-Polar Isolation
- Front-to-Back: > 30 dB
- Separation between Connectors: > 40 dB
- Impedance: 50 ohms
- Max Input Power: 50 W
- Lightning Protection: No
- DC Ground: Yes
Mechanical Specifications:
- Dimensions: 39.2 x 39.6 x 9.6 cm
- Weight: 2.9 kg
- Connector: RJ45
- Material: ABS
- Waterproof level: IP67
- Operating temperature: from -40 °C to 80 °C
Mounting Kit:
- Dimensions: 9.9 x 10.5 x 14.8 cm
- Regulation Range: +/- 30°
- Weight: 0.87 kg
- Mast Dimensions Range: 250 - 650 mm
- Material: Polyamide with fiberglass + galvanized steel.
