Zumtobel Group LED continuous row luminaire TECTON C #42183322 5500-840L1500WBLDEWH TECTON batten luminaire

5570 lm
Price in EUR including VAT
Delivered between Fri, 10.4. and Mon, 13.4.
More than 10 pieces in stock at supplier
free shipping

Luminous flux2

Product details

Linear, energy-efficient LED continuous row luminaire with highly efficient 64 mid-power LEDs per segment. Luminaire power: 31.1 W, DALI controllable luminaire with LED converter, for environmental sustainability and economic benefit. LED lifetime is 100,000 hours, with a luminous flux reduction to 95% of the initial value. Colour location tolerance initial MacAdam: 2. Luminaire luminous efficacy: 179 lm/W. Luminous flux: 5570 lm. Symmetrical wide beam luminaire. Colour rendering Ra 80, colour temperature 4000 K. Split lens concept to reduce perceived glare. Overlapping PMMA lenses, shatterproof up to IK07, provide IP50 protection for LED and optics. All-in-one solution: light bar, light source, and reflector combined in a single product, allowing 100% continuous LED light band without interruption. High-quality appearance in the same look as the trunking. Dimming level for DC mode preset to 15. LED continuous row luminaire made of sheet steel, painted in white polyester resin. 100% flexible and tool-free mechanical and electrical installation using CLIX technology with two side-mounted rotary levers on the corresponding trunking. No ultraviolet or infrared radiation. Ambient temperature: -20°C to 40°C. Note: For use in chemically aggressive environments, please consult your consultant. Dimensions: 1498 x 60 x 85 mm. Weight: 2.2 kg.

Key specifications

Material
Steel
Application range
Indoor
Dimmability
Dimmable
Scope of illuminant
incl. fixed light bulb
Width
6 cm
Height
8.50 cm

General information

Item number
33647722
Manufacturer
Zumtobel
Category
Wall lamps + Ceiling lamps
Manufacturer no.
42183322
Release date
17.5.2023

Colour

Colour
White
Exact colour description
White

Material

Material group
Metal
Material
Steel

Application range

Application range
Indoor

Lamp properties

Wall & Ceiling Light Type
Light strip
Dimmability
Dimmable
Dimmer control
Dali

Bulb properties

Scope of illuminant
incl. fixed light bulb
Bulb type
LED light
Housing
Matt
Luminous flux
5570 lm
Light colour
Neutral White
Colour temperature
4000 K
Colour rendering index
80
Lamp service life
100000 h
Number of lights
1x
Max. power per lamp
31.10 W

Smart home features

Smart home
Not compatible

Power supply

Power supply
Electrical connection
Input voltage
220 - 240 V
Conventional energy consumption
31.10 W
Power consumption
31.10 W

Safety

Protection type (IP code)
IPX2

Origin

Country of origin
Austria

Voluntary climate contribution

CO₂ emissions
24,75 kg
Climate contribution
EUR 0,62

Scope of delivery

Items per sales unit
1x

Product dimensions

Length
149.80 cm
Width
6 cm
Height
8.50 cm
Weight
2.20 kg
