ABB Stotz S&J Automatic circuit breaker S201P-K1,6 Manufacturer: ABB Stotz S&J Designation: Automatic circuit breaker proM Compact Type: S201P-K1,6 Installation depth: 68 mm Tripping characteristic: K Number of poles (total): 1 Number of fused poles: 1 Rated current: 1,6 A Rated voltage: 230 V Rated insulation voltage Ui: 440 V Rated impulse withstand voltage Uimp: 4 kV Rated breaking capacity Icn according to EN 60898 at 230 V: 12.5 kA Voltage type: AC/DC Rated breaking capacity Icn according to EN 60898 at 400 V: 12.5 kA Rated breaking capacity Icu according to IEC 60947-2 at 230 V: 25 kA Rated breaking capacity Icu according to IEC 60947-2 at 400 V: 25 kA Frequency: 50..60 Hz Energy limitation class: 3 Flush mounting: no Switching neutral: no Overvoltage category: 3 Degree of pollution: 3 Additional devices possible: yes Width in pitch units: 4 Protection class (IP): IP20 Ambient temperature during operation: -25..55 °C Connectable conductor cross-section stranded: 0..16 mm² Connectable conductor cross-section solid: 0..25 mm²ABB Stotz S&J automatic circuit breaker S201P-K1,6: further detailsThe automatic circuit breakers of the S 200 P series protect cables and wires against overloads and short circuits in accordance with DIN VDE 0100-430 and DIN VDE 0100-530. They comply with the construction regulations DIN VDE 0641-11 or IEC/EN 60898-1, DIN VDE 0660-101 or IEC/EN60947-2 and UL1077. For better visibility during wiring, the connection opening for cables is located above the connection opening for the phase rail. Conductor cross-sections up to 25 mm² can be connected directly to the device via the terminal block with insulation in protection class IP20. The extensive range of accessories offers you everything you need for your installation tasks. Numerous approvals make the S 200 P fit for worldwide use. Each unit is subjected to three intensive tests for quality and performance before delivery. , EAN: 4016779592260
