Berker plug-in with earth pin 6745643501

Manufacturer: Berker
Designation: Plug-in, earth pin with red hinged cover
Type: 6745643501
Version: Earth pin
Earth contact: Yes
Earth contact round: Yes
Number of active contacts (round): 2
With signal lamp: No
With built-in USB power supply: No
Type of USB power supply: Other
Number of units: 1
Number of phases: 1
Overprint/marking: Without
Connection type: Plug-in terminal
With hinged cover: Yes
With increased touch protection: No
Text field/inscription area: No
Colour: Grey
RAL number (similar): 7011
Metallic colour: No
Transparent: No
Lockable: No
Ejector mechanism: No
Insulated installation: Yes
With function light: No
With orientation light: No
Overvoltage protection: No
Residual current protection: No
With microfuse: No
Special power supply: Without special power supply
Mounting type: Surface-mounted
Mounting type: Fastening with screw
Material: Plastic
Material grade: Thermoplastic
Halogen-free: Yes
Surface protection: Untreated
Finish: Matt
Antibacterial treatment: No
With on/off switch: No
With loop-through function: No
Twisted central insert: No
Rated current: 16 A
Rated voltage: 250 V
Frequency: 50 Hz
Suitable for protection class (IP): IP55
Device width: 76 mm
Device height: 76 mm
Device depth: 63.1 mm
Compatible with Apple HomeKit: No
Compatible with Google Assistant: No
Min. device socket depth: 0 mm
Compatible with Amazon Alexa: No
IFTTT support available: No
Cover: Complete housing
For "difficult conditions" (according to VDE): No

Further details: Socket outlet with earth pin and red hinged cover, 2-pole + earth, screwless terminals, entry for 2 leads and lead + pipe, full-surface seal on rear of housing for rear cable entry and plaster compensation.
EAN: 4011334423324.
