Dehn DB M 1 320 Coordinated lightning current arrester type 1 DEHNbloc M
Product details
The DB M 1 320 Coordinated Lightning Current Arrester Type 1 DEHNbloc M from Dehn is a highly advanced protection device specifically designed for use in low-voltage consumer installations. This single-pole lightning current arrester meets the requirements of the standard EN 61643-11 and is based on spark gap technology. It consists of a base unit and a plug-in protection module, allowing for flexible and modular installation. The RADAX-Flow follow current limitation ensures high system availability by effectively minimizing the effects of overvoltages caused by direct lightning strikes. The lightning current arrester is suitable for use in lightning protection zones at interfaces 0A to 1, providing reliable protection for electrical systems.
- Modular design with base unit and plug-in protection module
- Maximum system availability through RADAX-Flow follow current limitation
- Protection against overvoltages from direct lightning strikes
- Suitable for use in lightning protection zone concepts.
Surge protection type | Lightning current arrester |
Number of conductors | 1 x |
Test class | Type 1 |
Mounting type | Top-hat rail |
Item number | 23984984 |
Manufacturer | Dehn |
Category | Surge protection |
Manufacturer no. | 961130 |
Release date | 16.11.2022 |
Surge protection type | Lightning current arrester |
Number of conductors | 1 x |
Lightning impulse current | 25 kA |
Rated leakage surge current | 50 kA |
Nominal voltage | 320 V |
Protection level | 2.50 V |
Mounting type | Top-hat rail |
Test class | Type 1 |
Protection type (IP code) | IP20 |
Country of origin | Germany |
