The limit C 2 Type 3P 15 kA 3 kV (952307) from Dehn is a highly advanced surge arrester specifically designed for the protection of low-voltage consumer installations. This multipole surge arrester belongs to the Type 2 testing class according to EN 61643-11 and provides a reliable solution for safeguarding against surges caused by lightning strikes or other electrical disturbances. The arrester is equipped with an innovative arrester monitoring system that ensures high device safety through the Thermo-Dynamics Control System. It is suitable for use in lightning protection zones 0B 1 and higher and can be easily mounted on a DIN rail. With a lightning impulse current of 15 kA and a nominal discharge current of 25 kA, it offers effective protection for electrical systems.

• Thermo-Dynamics Control for enhanced device safety
• Suitable for lightning protection zones 0B 1 and higher
• Easy installation on DIN rail
• Protection class IP20 for indoor use
• Rated voltage of 480 volts for versatile applications.
