Doepke DRCBO 4 C20/0.30/3N-

Price in EUR including VAT
was EUR1449,–
Ratings
Delivered between Sat, 9.8. and Thu, 14.8.
Only 1 piece in stock at supplier
free shipping

Product details

The DRCBO 4 C20/0,30/3N- from Doepke is a highly advanced combination RCD/MCB that integrates both residual current and circuit protection in a single device. This product provides comprehensive protection for people and electrical systems by safeguarding against earth faults, short circuits, and overloads. With a rated breaking capacity of 6 kA and an all-current-sensitive design, the switch can detect fault currents across a wide frequency range from 0 Hz to 150 kHz. Its compact design and independent tripping at fault currents of type A make it a flexible solution for various applications. The DRCBO 4 is particularly resistant to surge currents and lightning, enhancing its reliability in critical situations. Additionally, it features a separate indication of the tripping reason and a practical labeling window to facilitate handling.

  • All-current sensitive for fault currents from 0 Hz to 150 kHz
  • Low sensitivity at higher frequencies to prevent plant-related false tripping
  • Separate indication of the tripping reason for easy fault diagnosis
  • Compact size for all rated currents
  • Terminal clamps with a wide clamping cross-section range on both connection sides.

Key specifications

Circuit breaker type
Miniature circuit-breaker/residual current circuit-breaker combination
Length
67 mm
Width
45 mm
number of poles
4
Item number
33800074

General information

Manufacturer
Doepke
Category
Residual-current device
Manufacturer no.
09948135
Release date
17.5.2023

Circuit Breaker Features

Circuit breaker type
Miniature circuit-breaker/residual current circuit-breaker combination
number of poles
4
Tripping characteristic
C
Rated current
20 A
Rated current
0.3 A
Rated voltage
400 V
voltage type
AC
Rated insulation voltage Ui
440 V
Protection type (IP code)
IP20

Origin

Country of origin
Germany

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Length
67 mm
Width
45 mm

14-day cancellation right
30-day right of return if unopened
24 Months statutory warranty
