Grundfos Electronically controlled circulation pump MAGNA3 80-120 F 360 mm DN 80 97924690

Price in EUR including VAT, free shipping
Ratings
Delivered between Fri, 6.6. and Tue, 17.6.
Only 2 items in stock at supplier

Product details

Electrically controlled - Single pump - Cast ironFurther technical features:- Pump circuit: other- Insulation class according to IEC: F- Pump height: 318- Max. medium temperature (continuous operation): 110- Installation length: 360mm- Type of speed control: infinitely variable- Delivery head at nominal flow rate: 95.98 Medium temperature (continuous operation): 110- Installation length: 360mm- Type of speed control: stepless- Delivery head at nominal flow rate: 95.98- Min. medium temperature (continuous operation): -10- Communication bus: possible with accessories- Energy efficiency index (EEI): 0.17- Oval flange shape: No- Nominal flow rate: 37.41- Pressure stage item: PN 6- Electrical connection: Connection terminals- Motor speed control: Built-in- Frequency: 50/60 Hz- Double pump: No- Material impeller/pump wheel: Plastic- Absorbed motor power (P1): 1496kW- Speed: 36901/min- Rated current: 6.65A- Nominal diameter: DN 80

zero.

Key specifications

Maximum flow rate
37.41 l/min
Power
1496 W
Max. Delivery pressure
10 bar
Item number
24946497

General information

Manufacturer
Grundfos
Category
Water pumps
Manufacturer no.
97924690
Release date
23.9.2022

Water Pump Features

Power
1496 W
Maximum flow rate
37.41 l/min
Max. Delivery pressure
10 bar
Protection type (IP code)
IPX4

Power supply

Power supply
Electrical connection

Voluntary climate contribution

CO₂-Emission
Climate contribution

Product dimensions

Length
36 cm
