Accuracy according to DIN 2270, automatic switching of the measurement direction. Essential bearing points of the measuring instruments are mounted in precision bushings. The feeler lever shaft is supported in precision ball bearings. Housing is chrome-plated. Antimagnetic display (ordinary magnetic fields have no influence on the reading). Three milled dovetail guides for holding the clamping shaft. Rotatable graduation scale. The length specifications of the measuring inserts (measuring insert length mm) refer to the center of the ball measuring insert with a 2 mm HM ball measuring insert thread M1.6. Other technical features: Design: measuring insert pivotable to the dial, inspection required: yes.

Delivery includes clamping shaft Ø 8 mm h6 and key. Calibration available upon request and for an additional charge.
