Legrand miniature circuit-breaker 404189 Manufacturer :Legrand Designation :Miniature circuit-breaker C20A 1-pole+N 10kA Type :404189 Mounting depth :44 mm Tripping characteristic :C Number of poles (total) :2 Number of fused poles :1 Rated current :20 A Rated voltage :230 V Rated insulation voltage Ui :500 V Rated impulse withstand voltage Uimp :4 kV Rated breaking capacity Icn according to EN 60898 at 230 V :10 kA Voltage type :AC Frequency :50..60 Hz Energy limitation class :3 Flush mounting :yes Switching neutral conductor :yes Degree of pollution :2 Additional devices possible :yes Width in pitch units :2 Protection class (IP) :IP20 Explosion-proof :no Legrand miniature circuit-breaker 404189: further details Legrand miniature circuit-breaker TX3 according to EN 60898-1, VDE 0641-11, EN 60947-2, 1-pole with connecting neutral, C-characteristic, rated current In 20 A, rated breaking capacityIcn10 kA according to EN 60898-1, rated voltage Un 230 VAC, rated frequency 50/60 Hz, energy limitation class 3, mounting on DIN rail EN 60715 by means of a latching quick-release fastening, clear information on the front of each unit, clear switch position information on the front of each unit.clear information on the front of each device, clear red/green switch position indication on the switch lever, with labelling window, with plug-in protection for safe insertion of the conductor into the lift terminal, mounting of auxiliary devices possible. Miniature circuit breakers with C-characteristic are designed for line protection of devices with high inrush currents (e.g. motors and transformers). , EAN: 3414970393791.
