Mersen Load Break Switch Neozed 05861.063100

Manufacturer: Mersen
Designation: Load Break Switch Neozed D02 20A/230/400V 2-p
Type: 05861.063100
Number of Poles: 2
Size: D02
Rated Voltage: 230 V
Rated Current: 63 A

The D0-Linocur is a combination of a load break switch and a Neozed fuse element rated at 63 A, equipped with significant safety features and advanced switching and clamping technology. The power output of the Neozed fuse inserts leads to internal heating of the Linocur device. To prevent overheating of the device and unwanted premature tripping of the fuse insert, specific design measures have been implemented: generously sized conductors made of solid copper, strong external spring support under the foot contact, large-area heat transfer through contact via screw cap, extensive contact area at the foot contact, and special contacts with functional separation. Thanks to this design, the Linocur offers one of the lowest values in terms of power loss in the market for D0 fuse units.

EN/IEC 60947-3, DIN VDE 43880, DIN VDE 0660 Part 107, DIN VDE 0638, DIN VDE 0636 Part 3, IEC 60269-3, EAN: 3605340496079.
