OBO Bettermann PDP-2x2-24-D-OS data cable protection

Manufacturer: OBO Bettermann
Designation: Data cable protection
Type: PDP-2x2-24-D-OS
Highest continuous voltage AC: 21 V
Highest continuous voltage DC: 30 V
Rated leakage current (8/20): 10 kA
Protection level core/core: 150 V
Protection level core/earth: 850 V
Frequency: 0...100 MHz
Cut-off frequency: 100 MHz
Signalling on device: Without
Mounting type: TH35 top-hat rail

Further details:
Plug-in data cable protection type 1+2/D1+C2 for use in measurement and control technology. Protection device for multi-core systems. Direct shield earthing. Frequency range up to 100 MHz. Earthing via top-hat rail or connection cable possible. Small overall width of 12.5 mm. High system availability - no signal interruption without protective module. With optical signalling and possibility of remote signalling via power supply PDP-PS.

Application: Universal lightning and surge protection for data transmission devices in MCR technology.
EAN: 4012196742264.
