OBO Bettermann PV System Solution PVG-C1000S110

Manufacturer: OBO Bettermann
Designation: PV system solution in housing
Type: PVG-C1000S110
DC Network Type: Yes
IT Network Type: No
TN Network Type: No
TN-C Network Type: No
TN-C-S Network Type: No
TT Network Type: No
Other Network Type: Yes
Max. Fault Current (8/20): 40 kA
Max. Continuous DC Voltage: 1000 V
Max. PV Voltage: 1000 V
Mounting Type: Other
Size: Other
Max. Conductor Cross-Section Rigid (Solid/Multi-Stranded): 35 mm²
Max. Conductor Cross-Section Flexible (Fine-Stranded): 35 mm
Max. Conductor Cross-Section Flexible (Flexible): 25 mm²
Signal Indication on Device: Optical
Protection Class (IP): IP66

Additional Details:
Type-2 system solution with MC4 connector for PV inverters with 2 separate MPP trackers. Varistor surge protector, pluggable with disconnection device in fault-resistant Y-circuit according to VDE 0100-712 (50539-12). Low DC protection level: < 4.0 kV (Uoc max = 1000V DC with V20-C/0-500PV). One PV string input (MC4 connector) to one MPP inverter input, up to 30A DC per connection. Pre-assembled in a polycarbonate housing (IP66), UV resistant for outdoor use. For the DC protection of the inverter in PV systems. Additional measures are required in case of condensation risk due to wind, ice, temperature, or sunlight!.
