OBO Bettermann DS-TNC M/W protective device Manufacturer :OBO Bettermann Designation :130V protective device Type :DS-TNC M/W Nominal voltage DC :130 V Maximum continuous voltage AC :130 V Maximum continuous voltage DC :185 V Lightning impulse current (10/350 µs) :2.5 kA Rated load current :10 A Protection level :800 V Protection level wire/wire :800 V Protection level wire/earth :800 V Frequency :0 MHz Cut-off frequency :4000 MHz Mounting type :Connector/cable adapter Connection 1 :Aerial coaxial plug Arrester monitoring :no With remote signalling contact :no Explosion-proof version :no Protection class (IP) :IP40 OBO Bettermann DS-TNC M/W protection device: Further details Coaxial data cable protection devices ¿ Basic protection ¿ High pulse current carrying capacity 2 x 2.5 kA (10/350)¿ Simple installation (intermediate plug), m = plug, w = socket¿ Various plug combinations¿ Optimum transmission behaviour¿ With TNC connector¿ Includes OBO Quick clip M25 for simple installation , EAN: 4012195087250.
